Mercedes-Benz 386 Installation Instructions

Accessories
Installation Instructions
Mobile phone bracket Apple iPhone
© 2008, Daimler AG
11/08
03F074-08
Contents
Fitting the holder
Inserting the mobile phone
Pairing the mobile phone with
the cradle
Connecting the mobile phone
to the cradle
Switching to hands-free mode
General notes on operation
Using the iPod functions
Removing the mobile phone
Removing the cradle
1
2
G
Risk of accident
4
5 Please comply with the legal regula-
tions of the country in which you are
6
driving when you are using the tele-
phone inside the vehicle.
7
If it is legally permissible to use the
8
telephone while driving, only do so
9
when traffic conditions allow for it.
9 You may otherwise become distrac-
ted from the traffic, which may lead
10
to an accident in which you or
10
others may be injured.
For safety reasons, only use the
hands-free system when making
calls while driving.
When you are using the mobile pho-
ne via the hands-free system, drive
with extra caution, close all windows
and try to eliminate background
noise.
Please pull over or park the car if
you do not wish to use the hands-
free system to make a call. Do not
stop the vehicle or park where it is
prohibited to do so.
Place the telephone module into the
cradle only while the vehicle is at a
standstill. You could otherwise be
distracted and cause an accident.
Validity
These installation instructions are valid for
vehicles equipped with a
• Mobile phone fitting with interface
(Code 386) or
• Mercedes-Benz mobile phone
(code 388)
Each in combination with Apple iPhone 3G.
Components
• (1) Mobile phone cradle including
connector plug for the Media
Interface / iPod Interface Kit
In the following text, this will be referred to
as "cradle".
Notes
Please contact a qualified specialist work-
shop if you encounter difficulties when fit-
ting the telephone module. Mercedes-Benz
recommends that you use a Mercedes-Benz
Service Centre for this purpose.
The manufacturer reserves the right to
change technical details from those shown
in the illustrations contained in these instal-
M+P-03F-7172
lation instructions.
These installation instructions also refer to
the COMAND and Audio Operating Instruc-
tions, the vehicle Owner's Manual and the
mobile phone operating instructions. Please
keep them handy for reference.
At high outside temperatures, the cradle can
become very hot when in operation, as is the
case with the vehicle interior itself.
Do not open up the cradle and do not make
any modifications on the cradle. Otherwise
the type approval will be rendered invalid.
3
Fitting the holder
1. Slide the cradle (1) onto the contact
plate (2) until it audibly engages.
1
4
2
1
M+P-03F-7173
