Husqvarna CTH160 II Spare Parts

Husqvarna CTH160 II Spare Parts

Hide thumbs Also See for CTH160 II:

Advertisement

Table of Contents

See also: Instruction Manual
7
S E R V I C E
I0100043
IPL, CTH 160 II, 2001-02, 106 26 97-61
HECTH1602D, HECTH1602E
CTH160
II
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
106 26 97-61

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTH160 II and is the answer not in the manual?

Questions and answers

Related Manuals for Husqvarna CTH160 II

Summary of Contents for Husqvarna CTH160 II

  • Page 1 S E R V I C E I0100043 IPL, CTH 160 II, 2001-02, 106 26 97-61 HECTH1602D, HECTH1602E CTH160 Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar 106 26 97-61...
  • Page 2 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 ELECTRICAL...

  • Page 3: Repair Parts

    REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 ELECTRICAL PART DESCRIPTION 532144927 Battery 12 Volt 35 AMP Wet 874760412 Bolt Hex Hd 1/4-20 Unc X 3/4 532153664 Switch Interlock Push-In 532166181 Harness Asm Light W/4152J 532004152 Bulb Light #1156 532124780 Cable Starter 6Ga 11"...

  • Page 4: Chassis And Enclosures

    REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 CHASSIS AND ENCLOSURES...
  • Page 5 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 CHASSIS AND ENCLOSURES PART PART DESCRIPTION DESCRIPTION 532169831 Chassis 532170256 Bracket Exten Chassis Lh CRD 532165606 Drawbar 532175770 Bracket Exten Chassis Rh CRD 817060612 Screw 3/8-16 x .75 532165605 Support Battery CRD 532155272...
  • Page 6 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 DRIVE...
  • Page 7 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle Hydro Gear 321-0510 532121748 Washer 25/32 x 1-5/8 x 16 Ga. (Order parts from transaxle 532170006 Asm, Shaft manufacturer)

  • Page 8: Steering Assembly

    REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 STEERING ASSEMBLY...
  • Page 9 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 STEERING ASSEMBLY PART DESCRIPTION 532166627 Steering Wheel 532172393 Axle Cast Lt Machined 532169840 Spindle Assembly, L.H. 532169839 Spindle Assembly, R.H. 532124931 Bearing, Race, Thrust, Hardened 532121748 Washer 25/32 x 1-5/8 x 16 Gauge 812000029 Ring, Klip 532169832...

  • Page 10: Seat Assembly

    REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 SEAT ASSEMBLY PART PART DESCRIPTION DESCRIPTION 532140840 Seat 872050412 Bolt Rdhd Sht Nk 1/4-20x1-1/2 532121249 Spacer Split 28 X 88 Zinc 532140551 Bracket Pnt Pivot Seat (blk ) 532145006 Clip Push In Hinged 532123740...

  • Page 11: Wheels And Tires

    REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 DECALS MAX + _ 90N MAX + _ 150N PART PART DESCRIPTION DESCRIPTION 532145498 Decal Read Owner’s Manual Sym 532159737 Decal Brake/Clutch Symbol Lt 532170726 Decal Hood Rh 532166959 Decal Warn Back Plate CRD 532159736...

  • Page 12: Optional Equipment

    REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 ENGINE OPTIONAL EQUIPMENT Spark Arrester...
  • Page 13 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 ENGINE PART DESCRIPTION 532170771 Control Throt 817720410 Screw Hex Thd Cut 1/4-20x5/8 T - - - - - - - - Engine B&S Model 303777 (Order parts from engine manufacturer) 532149723 Muffler Twin Lo-Twin 532122434...

  • Page 14: Mower Lift

    REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 MOWER LIFT 17 18 20...
  • Page 15 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 MOWER LIFT PART DESCRIPTION 532159460 Washer Asm Inner Spring W/Plunger 532159471 Shaft Asm. Lift 532105767 Pin Groove 812000002 E Ring #5133-62 819211621 Washer 21/32 x 1 x 21 Ga. 532120183 Bearing Nylong 532125631...
  • Page 16 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 MOWER...
  • Page 17 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 MOWER PART PART DESCRIPTION DESCRIPTION 532169160 Housing Asm. Mower 532176291 Bracket Gauge Wheel Lf 872140506 Bolt Rdhd Sqnk 5/16-18 Unc x 3/4 532176292 Bracket Gauge Wheel Rf 532165569 Bracket Asm.
  • Page 18 REPAIR PARTS TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 BAGGER PART PART DESCRIPTION DESCRIPTION 532170690 Tube Handle Bagger CRD 532165781 Bracket Side Bagger CRD 872140416 Bolt Carriage 1/4-20 X 2.0 Gr.5 532165782 Tube Upper Bagger CRD 532123976 Nut Lock 1/4 Lge Flg Gr.
  • Page 19 TRACTOR- -MODEL NO. CTH160II (HECTH1602E), PRODUCT NO. 954 17 00-22 SCHEMATIC AMMETER (OPTIONAL) SOLENOID BATTERY STARTER PTO (DISENGAGED) FUSE WHITE BLACK WHITE WHITE BLACK BLACK BLACK FBI BUZZER SWITCH CLUTCH / BRAKE ELECTRIC CLUTCH (PEDAL UP) INTERLOCK BLACK BAGGER RELAY BLACK BLACK BLACK...
