User Manual
QuickSpecs
Overview
1. Menu
Opens, selects or exits the OSD menu.
2. Minus "-"
If the OSD menu is on, press to navigate
backward through the OSD menu and
decrease adjustment levels.
3. Plus"+"/Input
If the OSD menu is on, press to navigate
forward through the OSD menu and increase
adjustment levels.
If the OSD menu is inactive, press to activate
the source button that chooses the video
signal input (DisplayPort, HDMI, DVI or VGA).
DA - 14755 North America — Version 3 — January 16, 2014
4. OK/Auto
If the OSD menu is on, press to select the
highlighted menu item. If the OSD menu is
inactive, press to activate the auto
adjustment feature to optimize the screen
image.
5. Power/Power LED Turns the monitor on or off.
LED:
fully powered = white;
sleep mode = amber;
sleep timer mode = flashing amber.
HP Z30i 30-inch IPS Display
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HP Z30i
Summary of Contents for HP Z30i
- Page 1 QuickSpecs HP Z30i 30-inch IPS Display Overview 1. Menu Opens, selects or exits the OSD menu. 4. OK/Auto If the OSD menu is on, press to select the highlighted menu item. If the OSD menu is inactive, press to activate the auto adjustment feature to optimize the screen image.
- Page 2 QuickSpecs HP Z30i 30-inch IPS Display Overview Use two HP Z30i 30-inch IPS Displays for a high productivity work solution. (Multi-monitor support depends on your PC capability.) Model: D7P94A4, D7P94A8, D7P94AS, D7P94AT DA - 14755 North America — Version 3 — January 16, 2014...
-
Page 3: Technical Specifications
QuickSpecs HP Z30i 30-inch IPS Display Technical Specifications Panel Type 30-inch IPS Gen 2, LED Backlit Screen Size 75,78 cm (29.83 in.) widescreen; diagonally measured (diagonal) Panel Active Area 64,12 x 40,08 cm (25.24 x 15.78 in) (W x H) - Page 4 QuickSpecs HP Z30i 30-inch IPS Display Technical Specifications 1280 x 1024 @ 60 Hz 1366 x 768 @ 60 Hz 1440 x 900 @ 60 Hz 1600 x 900 @ 60 Hz 1600 x 1200 @ 60 Hz 1680 x 1050 @ 60 Hz...
- Page 5 QuickSpecs HP Z30i 30-inch IPS Display Technical Specifications Integrated Quick An easy-to-use, VESA-compliant, LCD monitor mounting solution that allows you to quickly and securely attach an LCD monitor to a variety of stands, brackets, Release arms or wall mounts. Cable Management Enhanced cable management for easy concealment of power, video and USB cables.
-
Page 6: Additional Information
61 g Impact RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations, including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,... - Page 7 Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards. End-of-life Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: Management and http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.
- Page 8 Simply mount an HP Thin Client to the Kit's VESA plate, slide it into place on to the product's the back of an HP Z24i, Z27i or Z30i IPS Display stand, and you're ready to go. QuickSpecs. HP Dual Output USB...
- Page 9 HP Z30i 30-inch IPS Display Technical Specifications © Copyright 2014 Hewlett-Packard Development Company, L.P. 1. ENERGY STAR® power is measured with factory defaults, brightness at ENERGY STAR® level of 200 cd/m2 and with no USB loads. 2. Default Power is measured with factory defaults, including factory default brightness and USB ports loaded at 25% of maximum.
