Data Sheet
FUJITSU Server PRIMERGY TX120 S3p Tower Server

Technical details

PRIMERGY TX120 S3
Housing types
Storage drive architecture
Mainboard
Mainboard type
Chipset
Processor quantity and type
Processor
Memory slots
Memory slot type
Memory capacity (min. - max.)
Memory protection
Memory notes
Memory options
Interfaces
USB 2.0 ports
Graphics (15-pin)
Serial 1 (9-pin)
LAN / Ethernet
Management LAN (RJ45)
Onboard or integrated Controller
RAID controller
SATA Controller
SATA controller type notes
LAN Controller
Remote Management Controller
Trusted Platform Module (TPM)
Page 3 / 8
Ultra-compact form-factor
4x 2.5-inch SAS/SATA
D3049
Intel® C202
1 x Intel® Celeron® processor / Intel® Pentium® processor / Intel® Core™ i3 processor / Intel® Xeon® processor E3-
1200v2 product family
Intel® Celeron® processor G1610
(2C/2T, 2.60 GHz, TLC: 2 MB, Turbo: No, 1333 MHz, 55 W)
Intel® Core™ i3-3220 processor
(2C/4T, 3.30 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Pentium® processor G2120
(2C/2T, 3.10 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Xeon® processor E3-1220Lv2
(2C/4T, 2.30 GHz, TLC: 3 MB, Turbo: Yes, 1600 MHz, 17 W)
Intel® Xeon® processor E3-1220v2
(4C/4T, 3.10 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1230v2
(4C/8T, 3.30 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1240v2
(4C/8T, 3.40 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1265Lv2
(4C/8T, 2.50 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 45 W)
4
DIMM (DDR3) UDIMM
2 GB - 32 GB
ECC
Mix and match possible; with dual channel operation better performance (2 modules with equal capacity necessary).
Single channel (1 module) configuration possible.
4 GB (1 module(s) 4 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
8 GB (1 module(s) 8 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
10
1 x VGA
1 x RS-232-C
2
1 x dedicated management LAN port for iRMC S3 (10/100/1000 Mbit/s)
Optional front Service LAN port (10/100 Mbit/s)
4 port SATA with RAID 0/1/10 for HDDs
Intel® C200
4 port for internal SATA HDDs with RAID 0, 1, 10 for Windows and Linux
Intel® 82574L + Intel® 82579LM onboard, 2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration), iSCSI and PXE-Boot
via LAN, WoL for Intel® 82574L only.
Integrated Remote Management Controller (iRMC S3, 32 MB attached memory incl. graphics controller)
IPMI 2.0 compatible
optional TPM
Ultra-compact form-factor
2x 3.5-inch SATA (non hot-plug)
www.fujitsu.com/fts
