Data Sheet
FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel® Xeon® processor server

Technical details

PRIMERGY TX140 S1p
Housing types
Storage drive architecture
Power supply
Mainboard
Mainboard type
Chipset
Processor quantity and type
Processor
Memory slots
Memory slot type
Memory capacity (min. - max.)
Memory protection
Memory options
Memory modules notes
Interfaces
USB 2.0 ports
Graphics (15-pin)
Serial connection
LAN / Ethernet
Management LAN (RJ45)
Onboard or integrated Controller
RAID controller
SATA Controller
LAN Controller
Remote Management Controller
Trusted Platform Module (TPM)
Page 3 / 9
Tower
Tower
3.5-inch
2.5-inch
Standard
Standard
D3049
Intel® C202
1 x Intel® Pentium® processor / Intel® Core™ i3 processor / Intel® Xeon® processor E3-1200v2 product family
Intel® Core™ i3-3220 processor
(2C/4T, 3.30 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Pentium® processor G2120
(2C/2T, 3.10 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Xeon® processor E3-1220v2
(4C/4T, 3.10 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1230v2
(4C/8T, 3.30 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1240v2
(4C/8T, 3.40 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1265Lv2
(4C/8T, 2.50 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 45 W)
Intel® Xeon® processor E3-1270v2
(4C/8T, 3.50 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1280v2
(4C/8T, 3.60 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
4
DIMM (DDR3) UDIMM
2 GB - 32 GB
ECC
4 GB (1 module(s) 4 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
8 GB (1 module(s) 8 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
1600 MHz memory modules
10
1 x VGA
1 x serial RS-232-C, usable for iRMC or system or shared
2 x Gb/s Ethernet
1 x dedicated management LAN port for iRMC S3 (10/100/1000 Mbit/s)
Management LAN traffic can be switched to shared onboard Gbit LAN port
Optionally integrated RAID 0/1 or RAID 5/6 controller for SAS base units (occupies one PCIe slot).
additional RAID controller options are described under Components RAID controller
Intel® C200, 2 ports used for accessible drives
4 port for internal SATA HDDs with RAID 0, 1, 10 for Windows and Linux;
Intel® 82574L + Intel® 82579LM onboard, 2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration), iSCSI and PXE-Boot
via LAN, WoL for Intel® 82574L only.
Integrated Remote Management Controller (iRMC S3, 32 MB attached memory incl. graphics controller)
IPMI 2.0 compatible
Infineon / 1.2 (option)
Tower
Tower
3.5-inch
2.5-inch
Hot-plug
Hot-plug
www.fujitsu.com/fts
