- Page 1 Super Video to WXGA Converter External Cable TV Tuner Ambery Model Number: LCDT6 OPERATION MANUAL Corporate Website: http://www.ambery.com Contact Support: support@ambery.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Content …………………………………………………….………...…………. 1 About The TV Tuner ……………………………………………………………………...…2 Front & Rear Panels…….……………………………………………………….………….…3 Illustration of Basic Connection.…………………………………………………..……… …4 Setup Procedures….……………………………………..……………………………….…5-7 Remote Controller Description………………….…………………………….………………8 Operations……………………………………………………………….…………………9 -13 Specification ……………………………………………………..……………………………14 Trouble Shooting …………………………………………………………………..…………14 PACKAGE CONTENT Before the installation, please check the package of content. 1. - Page 3 ABOUT THIS VIDEO CONVERTER / TV TUNER MODULE This external cable TV tuner unit doubles as a video upconverter and switcher. With the advanced video processor built in, this multimedia unit delivers outstanding video quality that surpasses your home TV display. Simply connect multiple video sources from CATV, DVD/VCR player, Camcorder, Video Game Consoles, Satellite Receiver, Video Camera or PC together thru this unit via AV/S-Video/VGA connections and select the desired input to watch any TV, DVD movies, computer screen or play video games on a desktop monitor, projector or flat panel TV with sharp and clean...
-
Page 4: Front & Rear Panels
FRONT & REAR PANELS Front Panels: Power Button Semi-transparent casing Input Button CH +/- Button Volume +/- Button Stereo Audio Input Composite Video Input S- Video Input Rear Panels: CABLE IN: Coax input for coax CATV cable from the wall. Video Out: This video converter tuner model can also convert the coax CATV... -
Page 5: Illustration Of Basic Connection
ILLUSTRATION OF BASIC CONNECTION Front View DVD/VCD GAMECUBE Camcorder X-Box Back View Antenna or CATV Audio Cable Sound Card Audio Cable Speaker VGA Card VGA Cable VGA Cable Monitor or LCD PC Back Panel Power Adaptor *All brand names and trademarks stated or illustrated are related to their respect owners. -
Page 6: Setup Procedures
SET UP PROCEDURE (1.) Set up cable connection when using a LCD/CRT monitor (In this section you will see TV pictures after finishing the installation) a. Connect the coaxial CATV cable from the wall into the RF input (“CABLE IN” port) in the back panel of TV tuner module. - Page 7 Set up cable connection when connecting with a PC. (In this section, you will watch TV while using your PC at the same time after finishing all the installation.) Connect the coaxial CATV cable from the wall into the RF input (“CABLE IN” port) in the back panel of TV tuner module.
- Page 8 Connection with satellite receiver, set top box, video game console, DVD/VCR player or another Video Appliances, Please use composite RCA video cable or s-video cable for cable connection. (In this section, you can watch video showing on the screen while finishing all the installation.) Follows the previous steps to connect the output from this TV tuner module to your monitor display properly using VGA cable.
-
Page 9: Remote Controller Description
REMOTE CONTROLLER DESCRIPTION All Functions Of The IR Remote Controller Power : Turn on/off this video converter/TV tuner module or MUTE: Press this button used for TV <->PC mode to mute the audio output selection from the 3.5mm mini stereo jack. Numeric Key: PIP: Press this button to... -
Page 10: Operations
Using This TV Tuner For The First Time… When the unit is powered up for the first time, the default input to the unit is TV(RF) input and there are no TV channels available yet. Users must train the tuner by using the channel scan function provided in the OSD operation menu to scan all the TV channels available in your area or from local cable TV service provider. - Page 11 1. Picture: For Video Quality Adjustment 1.Picture 1.Bright 2.Search 2.Contrast 3.Audio 3.Saturation 4.Setup 4.Hue 5.Time 5.Color temp. Normal /warm /cold 6.Access. 6.Picture mode Normal/user/bright/soft Bright: Adjust the brightness of the video output from the tuner. Contrast: Adjust the contrast of the video output images. Saturation: Adjust the color saturation of the video output images.
- Page 12 3 .Audio : For Audio Output Set-up And Controls 1. Picture 2. Search 3.Audio 1.volume 4. Setup 2.equalize 5.Time 6.Access Volume: change the output audio volume level. Equalize: change the balance of the audio output 4. Setup: System settings 1.OSD setting 1.
- Page 13 Factory mode: Reset all the previous setup back to the factory default settings. Description of sub item Bright: change the brightness of the OSD session. Mix: mixture of OSD and background Background: Change the background style for the OSD session. Signal Source : Change the input source.
-
Page 14: Specification
6 .Access : Some useful software 1. Picture 2. Search 3. Audio 4. Setup 5. Time Calendar 6. Access. Software ID Product Specification Item Specification CATV/TV Input 75 Ohm F female or IEC female Frequency range 48~862MHz Video Input AV(Composite Video), SV(S-Video) Audio Input (Signal Source) Stereo RCA Left + Right Channels Audio Input (PC) - Page 15 and looking at video channel 2 on TV for video display, you will not see the picture from the display because of the incorrect video channel being selected by mistake. Make sure that you do not set the VGA output resolution of this video converter beyond the maximum capacity that your monitor or projector can handle.
