Removing your monitor's pedestal
Removing your monitor's pedestal
This monitor is compliant with VESA Wall Mounting. You can remove
the monitor's pedestal to mount the monitor on a wall.
NOTE:
The VESA Wall Mount is not an HP accessory. It cannot be
ordered from HP. Contact your reseller for more
information.
CAUTION:
1 Place the monitor on a flat, clean surface with the pedestal fully
extended.
CAUTION:
2 Pull the plastic casing tabs apart (a), then lift off the casing (b) as
shown in the pictures below.
14 English
The LCD monitor is fragile.
Be careful not to trap your fingers when carrying out
step 2.
b
a
a
