Summary of Contents for Electrolux EWS 1030
-
Page 2: Table Of Contents
Dear customer, Transport damages Please read these operating instructions carefully When unpacking the appliance, check that it is not and pay particular attention to the safety notes damaged. If in doubt, do not use it and contact the indicated in the first pages. We recommend that you Service Centre. -
Page 3: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation General safety • All internal packing must be removed before using • Repairs to the machine must be carried out only by the appliance. -
Page 4: Disposal
Disposal Packaging materials The symbol on the product or on its packaging The materials marked with the symbol indicates that this product may not be treated as recyclable. household waste. Instead it shall be handed over to the applicable collection point for the recycling of >PE<=polyethylene electrical and electronic equipment. -
Page 5: Installation
Installation Positioning Unpacking Install the machine on a flat hard floor. All transit bolts and packing must be removed Make sure that air circulation around the machine is before using the appliance. not impeded by carpets, rugs etc. Check that the machine does not touch the wall or other kitchen You are advised to keep all transit devices so that units. -
Page 6: Water Drainage
The other end of the inlet hose which connects to the The drain hose must not be kinked. machine can be turned in any direction. Simply loosen the fitting, rotate the hose and retighten the fitting, making sure there are no water leaks For a correct functioning of the machine the drain hose must remain hooked on the proper support piece situated on the top part of the back... -
Page 7: Description Of The Appliance
Description of the appliance 1 Detergent dispenser drawer 2 Control panel 3 Door handle 4 Drain pump 5 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener, starch... -
Page 8: Use
Control panel Maximum temperatures are 90°C for cotton, 60°C for 1 ON/OFF button synthetic fabrics, 40°C for delicate fabrics, wool and (Ein/Aus - Marche/Arrêt) fabrics to be hand-washed. Position “Kalt/Froid” corresponds to cold wash. Press this button to switch the washing machine on. Press the button again to switch the machine off. -
Page 9: Option Button
the spin speed by means of button and then depress Start/Pause Important! If you accidentally press the button more than once, the display will show three blinking dashes. To drain the water, select any washing programme by means of the button, then press three times in order to select the DRAIN position (only the DRAIN light... -
Page 10: Skip/Reset Button
• Delay start, a time value indicated in hours and above the button will start flashing. To restart the selected by means of the relevant button. programme, press the button again. When you PAUSE the cycle and it becomes possible to open the door, provided •... -
Page 11: Delay Start Button
Depress RESET once, the pilot light WASH If you need to open the door, you must first set the goes out. washing machine to PAUSE by pressing the START/PAUSE button. After you have closed the • SPIN door, press the START/PAUSE button again. Depress RESET twice, the pilot lights WASH and RINSES go out. -
Page 12: Washing Hints
Laundry weights Washing hints The following weights are indicative: bathrobe 1200 g Sorting the laundry napkin 100 g Follow the wash code symbols on each garment quilt cover 700 g label and the manufacturer’s washing instructions. sheet 500 g Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. -
Page 13: Detergents And Additives
Ink: depending on the type of ink, moisten the fabric Quantity of detergent to be used first with acetone (*), then with acetic acid; treat any The type and quantity of detergent will depend on residual marks on white fabrics with bleach and then the type of fabric, load size, degree of soiling and rinse thoroughly. -
Page 14: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 15: Operating Sequence
4. Switch the machine on Operating sequence Press the ON/OFF button to switch the machine on. The display will show three blinking dashes or a Before the first wash we recommend that you pour 2 blinking zero. The light above the button will light up. litres of water into the main wash compartment of the detergent drawer in order to activate the ECO valve. - Page 16 10. Start the programme 7. Select the spin speed or the RINSE Press the START/PAUSE button . The relevant HOLD option light will stop flashing and only the light relevant to Press the SPIN SPEED button repeatedly, in the phase that is in progress will remain lit. order to select the desired spin speed or the RINSE If you have chosen a delayed start, the washing HOLD option.
- Page 17 13. How to open the door during the Check whether the drum is completely empty, by rotating it with your hand. The purpose of this is to cycle of a programme prevent any items of laundry from remaining accidentally in the drum, where they might get You can open the door, after having set the washing machine to PAUSE, provided the following damaged in a subsequent wash (e.g.
-
Page 18: Washing Programmes
Washing programmes Type of Consumption* Programme/ Description of laundry and Available options temperature programme Water symbols on load Energy kWh litres labels Cottons Main wash at 60°-90°C /RINSE HOLD 60°-90°C White cotton: PREWASH 3 kg 3 rinses e.g. sheets, Long spin tablecloths, SUPER RINSE household... -
Page 19: Maintenance
Maintenance 1. Door seal Detergent can also accumulate inside the drawer recess: clean it with an old toothbrush. Refit the Check from time to time the door seal and eliminate drawer after cleaning. eventual possible objects that could be trapped in the fold. -
Page 20: Water Inlet Filter
• Remove any objects from the pump impeller by Emergency emptying out rotating it. If the water is not discharged, proceed as follows to empty out the machine: • pull out the plug from the power socket; • close the water tap; •... -
Page 21: Something Not Working
Something not working? Problems which you can resolve yourself. During machine operation it is possible that one of the following alarm codes appears on the display: - E10: problem with the water supply - E20: problem with water draining - E40: door open Once the problem has been eliminated, press the START/PAUSE button to restart the programme. - Page 22 Problem Possible cause • The door will not open: • The water level is above the bottom edge of the door. • The machine is heating the water. • The drum is turning. • Spinning starts late or the • The electronic unbalance detection device has cut in because the laundry is not evenly distributed in laundry is not spun enough: the drum.
-
Page 23: Service Centre List
KUNDENDIENST Servicestellen Points de service Servizio dopo vendita 5506 Mägenwil/Zürich 1028 Préverenges 6916 Grancia Industriestr. 10 Le Trési 6 Zona Industriale E 9000 St. Gallen Zürcherstrasse 204 e 4127 Birsfelden Hauptstrasse 52 6032 Emmen Buholzstrasse 1 7000 Chur Comercialstrasse 19 3063 Ittigen/Bern Ey 5 Ersatzteilverkauf... - Page 24 The Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in...
