Sylvania SRC21134 Owner's Manual

13 inch/19 inch color tv/vcr
Hide thumbs Also See for SRC21134:
Table of Contents

Advertisement

Quick Links

OWNER'S
MANUAL
COLOR TV/VCR
SRC21134
SRC21194
This Owner's Manual is made of
recycled paper.
As an E
S
NERGY
TAR
Partner, our company has
determined that this product meets
the E
S
®
guidelines for
NERGY
TAR
energy efficiency. E
S
NERGY
a U.S. registered mark.
®
If you need additional assistance for set-up or operating
®
is
TAR
after reading owner's manual, please call
TOLL FREE : 1-800-968-3429
(13 inch)
(19 inch)
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
Please read before using this equipment

Advertisement

Table of Contents
loading

Related Manuals for Sylvania SRC21134

Summary of Contents for Sylvania SRC21134

  • Page 1 OWNER’S MANUAL COLOR TV/VCR SRC21134 (13 inch) SRC21194 (19 inch) This Owner’s Manual is made of recycled paper. INSTRUCCIONES EN ESPAÑOL INCLUIDAS. As an E ® NERGY Partner, our company has determined that this product meets If you need additional assistance for set-up or operating the E ®...

  • Page 2: C Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. THIS SYMBOL INDICATES THAT DAN- CAUTION GEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT RISK OF ELECTRIC SHOCK WITHIN THIS UNIT. DO NOT OPEN THIS SYMBOL INDICATES THAT THERE CAUTION: TO REDUCE THE RISK OF ELECTRIC...
  • Page 3 F IGURE A EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE ANTE NNA L EAD I N W I R E GROUND C L A M P A NTENNA DI SCHARG E UN I T (NEC SECTION 8 10 -2 0) EL ECT RI C SE RV I CE EQ U I PM EN T...

  • Page 4: C Precautions

    PRECAUTIONS PRECAUTIONS LOCATION IMPORTANT COPYRIGHT INFORMATION Unauthorized recording or use of broadcast televi- For safe operation and satisfactory performance of sion programming, video tape, film or other copy- your TV/VCR, keep the following in mind when righted material may violate applicable copyright selecting a place for its installation: laws.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS C IMPORTANT SAFEGUARDS ... . .2 C RECORDING ......20 NORMAL RECORDING .

  • Page 6: C Features

    Remote Control Unit 2 AA Batteries Rod Antenna (13” model only) PART NO. PART NO. (0EMN00673 or (N0124UD or N0155UD for SRC21134) 0EMN01599 or (N0145UD or N0157UD for SRC21194) 0EMN01755) • If you need to replace these accessories, please refer to the PART NO. under the illustrations and call 1-800- 968-3429.

  • Page 7: C Operating Controls And Functions

    - REMOTE CONTROL - Connects to earphones (not sup- EARPHONE jack– plied) for personal listening. The size of jack is [ SRC21134 ] 1/8” monaural (3.5mm). Connect to the audio output AUDIO input jack– jack of your audio equipment, video camera or...
  • Page 8 - REAR VIEW -* ANT. MENU button– Press to display the main menu on Press to rapidly advance the tape, F.FWD button– the TV screen. or to view the picture rapidly in forward during playback mode. (Forward Search) DISPLAY button– Display the counter or the cur- rent channel number and current time on the TV button–...

  • Page 9: C Preparation For Use

    PREPARATION FOR USE ANTENNA/CABLE CONNECTIONS From Cable System or Satellite Dish VHF/UHF Antenna Satellite Box or Rod Antenna (Not supplied) Cable Box (Supplied with 13” model only) OU T (Not supplied) VHF Antenna (Not supplied) UHF Antenna From (Not supplied) Cable System ANT.

  • Page 10: External Input Mode

    TO RECORD A SCRAMBLED/UNSCRAMBLED INSTALLING THE BATTERIES CHANNEL 1) Set the TV/VCR channel selector to the output 1)Open the battery compartment cover by pressing channel of the Cable Converter Box or Satellite the cover on the remote unit in the direction of the Box.

  • Page 11: Clock Set Up (Auto / Manual)

    Select “SETTING CLOCK” – M E N U – TO SELECT A DESIRED CHANNEL TIMER PROGRAMMING Press the MENU button on the PICTURE CONTROL B SETTING CLOCK CHANNEL SET UP remote control. You can select the desired channel by using the USER’S SET UP V-CHIP SET UP Press the PLAY/K or STOP/L but-...

  • Page 12: Channel Set Up Again

    NOTE: When unplugging the AC cord or if there is a power – M E N U – Select “SETTING CLOCK” failure for more than 30 seconds, you may have to TIMER PROGRAMMING PICTURE CONTROL Press the MENU button on the B SETTING CLOCK reset the clock.

  • Page 13: Selecting The Language

    Select “CHANNEL SET UP” Select “ENGLISH” or “ESPAÑOL” Press the MENU button on the Select “ENGLISH” or “ESPAÑOL”= Spanish using – M E N U – TIMER PROGRAMMING remote control. the F.FWD/B or REW/s button. PICTURE CONTROL SETTING CLOCK B CHANNEL SET UP Press the PLAY/K or STOP/L but- USER’S SET UP V-CHIP SET UP...

  • Page 14: C Tv Operation

    TV OPERATION WATCHING A TV PROGRAM PICTURE CONTROL The TV/VCR’s picture controls – BRIGHT, CON- TRAST, COLOR, TINT and SHARPNESS – are Turn on the TV/VCR preset to factory specifications. Although they are Press the POWER button to turn on the TV/VCR. usually the best, you may need to make some further adjustments for a natural looking image.

  • Page 15: Closed Caption System

    TO CANCEL THE CLOSED CAPTION CLOSED CAPTION SYSTEM SYSTEM You can view specially labeled (cc) TV programs, Repeat steps [1] and [2], select [OFF] using the movies, news, pre-recorded tapes with either a dia- F.FWD/B or REW/s button. Press the MENU but- logue caption or text display.

  • Page 16: Mpaa Rating Set Up

    Select your desired item Exit the V-Chip setting mode Press the PLAY/K or STOP/L but- Press the MENU button on the remote control to B TV–Y [VIEW] ton to point to your desired item. return to original mode. TV–Y7 ( [VIEW] TV–G [VIEW]...

  • Page 17: Fm Mode (Srt21134 Only)

    NOTES: FM MODE (SRC21134 only) • FM mode is not available for model SRC21194. This function enables you to receive FM radio broad- • The radio frequency indication repeats to appear casting. and disappear. • You can not record the FM radio wave broadcast- Set the FM mode ing.

  • Page 18: Auto Repeat Playback

    AUTO REPEAT PLAYBACK SEARCH PICTURE SEARCH The TV/VCR has an auto repeat function that allows you to repeat a tape indefinitely without touching the This feature is very useful in finding or skipping over PLAY button. a particular scene on a tape. In this mode, the sound Repeat playback from the beginning ALL REPEAT: will be muted.

  • Page 19: Slow Motion

    NOTES: SLOW MOTION • Time Search can be set up to a maximum of 9 hours 50 minutes (9:50) by 10 minutes at a time. Press the SLOW button to reduce the playback speed. • This function will not operate in recording mode. The TV/VCR mutes the sound during slow motion.

  • Page 20: Vertical Hold Control

    VERTICAL HOLD CONTROL TRACKING ADJUSTMENT In the Pause/Still mode only, when the picture begins • Tracking adjustment will be set automatically to vibrate vertically, stabilize the picture by pressing (Digital Tracking function) when you start play- the CHANNEL K or L button. back.

  • Page 21: Otr (One Touch Recording)

    Avoid overlap of programs ... OTR (One Touch Recording) There is a chance that a program will not be record- ed. When programs overlap: This function enables you to set the recording length • The program with the earliest start time will record simply by pressing the REC/OTR button on the first.

  • Page 22: Timer Program Extension

    For every day recording : To – TIMER PROGRAMMING – record a TV program at the same CH DATE BEGIN END Finish setting the program time on the same channel every -/- - - - - -:- - -:- - - - -/- - - - - -:- - -:- - - - Press the F.FWD/B or REW/s button.

  • Page 23: Hints For Automatic Timer Recording

    TO CANCEL AN AUTOMATIC TIMER RECORDING Set “AUTO RETURN” to [ON] – USER’S SET UP – Press the PLAY/K or STOP/L but- • After setting a program; RENTAL [OFF] ton to point to “AUTO RETURN”. REPEAT PLAY [OFF] B AUTO RETURN [ON] 1)Press the POWER button.

  • Page 24: Sleep Timer

    SLEEP TIMER Select “TV” or “TAPE” The Sleep Timer function turns off the TV/VCR Press the PLAY/K or STOP/L but- without using the POWER button after a desired ton until it points to “TV/TAPE”. period of time. Press the F.FWD/B or REW/s WAKE UP ON/OFF [ON]...

  • Page 25: C On Screen Display

    ON SCREEN DISPLAY To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows: WHEN THE CLOSED CAPTION MODE IS OFF: <Off mode>...

  • Page 26: C Troubleshooting Guide

    TROUBLESHOOTING GUIDE If you have followed the instructions contained in this manual and have difficulty in operating your TV/VCR, locate the PROBLEM in the left column below. Check the corresponding CORRECTIVE ACTION column to remedy the problem. PROBLEM CORRECTIVE ACTION •...

  • Page 27: C Specifications

    Audio S/N ratio : More than 43dB Video Heads : Rotary four-head OTHER SPECIFICATIONS Tape width : 1/2 inch Tape speed [ SRC21134 ] SP : 33.40mm/sec. Power requirement : AC 120V/60Hz LP : 16.67mm/sec. Power consumption : SLP : 11.12mm/sec.

  • Page 28: Panel Delantero

    - PANEL DELANTERO - CHANNEL POWER AUDIO VIDEO STOP/EJECT PLAY F.FWD VOLUME REC/OTR EARPHONE 2 3 4 5 6 7 8 1011 - CONTROL REMOTO - SRC21134 SRC21194 WAKE-UP WAKE-UP POWER /SLEEP TV/FM POWER /SLEEP EJECT CHANNEL RETURN CHANNEL RETURN...

  • Page 29: Panel Trasero

    - PANEL TRASERO - ANT. • Púlselo para introducir dígitos cuando establezca un 9 Indicador de grabación (RECORD)– Parpadea programa. durante la grabación. (Por ejemplo: Para ajustar el reloj o establecer un pro- Se enciende en el modo de espera de la grabación con grama de temporizador) temporizador.
  • Page 30 22 Botón de pausa/imagen fija (PAUSE/STILL)– rior), y al pulsarlo por segunda vez, el canal cambiará del 10 al 3. Púlselo para detener temporalmente la cinta durante la grabación o para ver una imagen fija durante la repro- 25 Botón del temporizador despertador/para ducción.
  • Page 31 MODO DE ENTRADA EXTERNA AJUSTE DEL RELOJ Cerciórese... Cuando utilice una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de • La alimentación del televisor/videograbadora deberá salida de audio/vídeo del equipo de reproducción a las estar conectada. tomas AUDIO IN/VIDEO IN de su En el ejemplo de abajo, el reloj va a ajustarse así: televisor/videograbadora.

  • Page 32: Limited Warranty

    LIMITED WARRANTY FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase.
