OWNER’S MANUAL COLOR TV/VCR SRC2213 This Owner’s Manual is made of recycled paper. ® As an E NERGY Partner, our company has determined that this product meets the E ® guidelines for NERGY ® energy efficiency. E NERGY a U.S. registered mark.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
Page 3
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE NEC - NATI O NAL EL ECTRI CAL CO DE S2 8 9 8 A 13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
LOCATION For safe operation and satisfactory performance of your TV/VCR, keep the following in mind when selecting a place for its installation: • Shield it from direct sunlight and keep it away from sources of intense heat. • Avoid dusty or humid places. •...
• Infrared remote control • Bilingual on screen menu display selectable in English or Spanish • This shows the elapsed record- Real time counter– ing or playback time in hours, minutes, and sec- onds. The “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.
OPERATING CONTROLS AND FUNCTIONS NOTE: • We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control. If you decide to use a universal remote control with this unit, please be aware that the code number given may not operate this unit.
Page 8
- REAR VIEW - [Fig.3] Press to rewind the tape, or to view REW button– the picture rapidly in reverse during playback mode. (Rewind Search) button– • Press to select a mode from a particular menu. (for example: LANGUAGE or USER’S SET UP) Press to begin playback.
PREPARATION FOR USE ANTENNA/CABLE CONNECTIONS From Cable System or Satellite Dish Satellite Box or Cable Box OU T (Not supplied) From Cable System 75-ohm Coaxial Cable (Not supplied) VHF/UHF COMBINED ANTENNA The VHF/UHF Rod Antenna (supplied) is detach- able. Insert the stem of the antenna into the hole on the upper-back portion of the TV/VCR.Connect the VHF/UHF Rod Antenna or VHF/UHF Combination Antenna to the ANT.
TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL 1. Set the TV/VCR channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3) 2.Select the channel to record from your Cable Converter Box or Satellite Box. EXTERNAL INPUT MODE When using an external input signal (another VCR or video camera), connect the player’s audio/video out- put cables to the AUDIO IN/ VIDEO IN jacks of...
TO SELECT A DESIRED CHANNEL You can select the desired channel by using the CHANNEL K or L button on or directly pressing the number buttons on the remote control. Note for using the number buttons: • When selecting cable channels which are higher than 99, press the +100 button first, then, press the last two digits.
Select “SETTING CLOCK” Press the MENU button on the remote control. Press the PLAY/K or STOP/L but- ton to point to “SETTING CLOCK”. Then, press the F.FWD/B button. Select “MANUAL CLOCK SET” Press the PLAY/K or STOP/L but- ton to point to “MANUAL CLOCK SET”.
Select “CHANNEL SET UP” Press the MENU button on the remote control. Press the PLAY/K or STOP/L but- ton to point to “CHANNEL SET UP”. Then, press the F.FWD/B button. Select “ADD/DELETE CH” Press the PLAY/K or STOP/L but- ton to point to “ADD/DELETE CH”.
WATCHING A TV PROGRAM Turn on the TV/VCR Press the POWER button to turn on the TV/VCR. Select the channel number Press the CHANNEL K or L button to select your desired channel number or press the number buttons on the remote control. Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be viewed must be selected...
CLOSED CAPTION SYSTEM You can view specially labeled (cc) TV programs, movies, news, pre-recorded tapes with either a dia- logue caption or text display. By choosing the caption mode, you CAPTION mode: can watch dramas, movies and news while captioning the dialogues and the contents of news.
Page 16
Select your desired item Press the PLAY/K or STOP/L but- ton to point to your desired item. Then, press the F.FWD/B button to select [BLOCK] or [VIEW]. • When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically.
CHANGE ACCESS CODE To change access code, follow the steps. Press the MENU button so that the TV/VCR SETUP display appears on the TV screen. Press the PLAY/K or STOP/L but- ton to point to "V-CHIP SET UP". Then, press the F.FWD/B button. Use the number buttons to enter 4- digit access code.
Select “ALL” or “BLANK” Press the PLAY/K or STOP/L but- ton to point to “REPEAT PLAY”. Press the F.FWD/B or REW/s button repeatedly until your desired selection [ALL] or [BLANK] appears. Exit the Repeat Play setting Press the MENU button on the remote control to return to the TV mode.
Begin Time Search By pressing the REW/s or F.FWD/B button, the TV/VCR will rewind or fast forward to the specified point. The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically. TO CANCEL THE TIME SEARCH at this point Press the STOP/EJECT button on the TV/VCR or the remote control.
TWO DIFFERENT TAPE SPEEDS Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long Play). The table below shows the maximum recording/play- back time using T60, T120 or T160 tapes in each mode. Tape Speed Recording/Playback Time Type of tape...
• To stop the OTR operation, press the STOP button on the TV/VCR or on the remote control. • To show the remaining time, press the DISPLAY button on the remote control so that “OTR” appears on the TV screen. (It will show up momentarily then disappear.) •...
Set the channel number Press the PLAY/K or STOP/L but- ton until the desired channel num- ber appears. (Example: CH61) Then, press the F.FWD/B button. Remember: If the TV/VCR is con- nected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.
TO CORRECT A PROGRAM • While setting a program; press the REW/s but- ton to go back one step and enter the correct num- bers using the PLAY/K or STOP/L button. • After setting a program; 1)Press the POWER button. 2)Repeat steps [1] - [2] on page 21.
Select “TV” or “TAPE” Press the PLAY/K or STOP/L but- ton until to point to “TV/TAPE”. Press the F.FWD/B or REW/s button, and select [TV] or [TAPE]. Set wake up time Press the PLAY/K or STOP/L but- ton until to point to “TIME”. Press the F.FWD/B or REW/s button until your desired wake up time appears.
To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows: WHEN THE CLOSED CAPTION MODE IS OFF: •...
TROUBLESHOOTING GUIDE If you have followed the instructions contained in this manual and have difficulty in operating your TV/VCR, locate the PROBLEM in the left column below. Check the corresponding CORRECTIVE ACTION column to remedy the problem. PROBLEM No power. No picture and sound.
CONTROLES DE OPERACIÓN Y SUS FUNCIONES NOTA: No recomendamos utilizar mandos a distancia universales. No todas las funciones pueden ser controladas mediante un mando a distancia universal. Si decide utilizar un mando a distancia universal con esta unidad, tenga en cuenta que con el número de código dado tal vez no se pueda controlar la unidad.
Page 29
10 Botón de avance rápido (F.FWD)– Púlselo para avanzar rápidamente la cinta, o para ver la imagen en avance rápido durante el modo de reproducción. (Búsqueda con avance rápido) Botón B– • Cuando establezca un programa (por ejemplo: para ajustar el reloj o para establecer un programa de tem- porizador), púlselo para determinar su elección y vaya al paso siguiente que quiera introducir.
Desde el cable coaxil o caja de emisiones vía Caja de CATV satélite de 75 ohm del o caja de emi- sistema de Cable siones vía satélite (no incluído) O UT Desde el sistema de Cable Cable coaxil de 75 ohm (no incluído) ANTENA COMBINADA DE VHF/UHF La antena de varilla de VHF/UHF (incluído) es desmontable.
PREPARACIÓN DE CANALES POR PRIMERA VEZ 1) Enchufe el cable de alimentación del televisor/videograbadora en una toma de CA estándar. NOTA: Si aparezcan algunos digitos en el rincón de la pantalla, pulse el botón POWER sin desenchufar el cable de alimentación. 2) Pulse el botón POWER para encender el televisor/videograbadora.
Page 32
Get it fixed, at your home or ours! For repair of major brand appliances in your own home… no matter who made it, no matter who sold it! 1-800-4-MY-HOME lawn equipment and electronics for repair, call for the location of your nearest Sears Parts & Repair Center. For the replacement parts, accessories and owner’s manuals that you need to do-it-yourself, call Sears PartsDirect 1-800-366-PART...
