- Page 1 User Manual airCUE-XM8 Version 03 CUE, a.s., K Nouzovu 6, 143 00 Praha 4, Czech Republic phone: +420 241 091 240 fax: +420 241 432 446 www.cuesystem.com mail: info@cuesystem.com...
- Page 2 User Manual airCUE-XM8 UM027_03, 15.11.2006 Copyright © CUE, a.s., Praha, Czech Republic 1990 - 2006. All rights reserved. Specifications are subject to change without prior notice.
-
Page 3: Table Of Contents
7.10. User Control Application........................28 7.11. Embedded Applications......................... 29 7.12. Taskbar ..............................29 Default Settings..........................30 8.1. airCUE-XM8 Network Setup........................30 Charging ............................33 9.1. Standard Charging ..........................33 9.2. Optional Docking Station........................34 10. Software and Firmware License....................35 11. -
Page 4: Introduction
Overview Since the time that CUE released the first beautifully crafted classically styled wooden touch panel, people have been asking for a wireless version. Here it is… CUE introduces the new Wi-Fi enabled 8.4” active color touch panel. This superior touch panel caters to the full integration of lifestyle as well as work style. It combines functionality such as multimedia integration, lighting automation, security monitoring, entertainment integration, and meeting &... -
Page 5: Airue-Xm8 Box Contents
Box Contents Each airCUE-XM8 comes with 1. Touch panel airCUE-XM8 2. Wireless Communication Wi-Fi Card 3. Charger incl. power cable 4. USB cable 5. Cleaning cloth 6. CE Declaration of Conformity 7. Data Sheet 8. CD User Manual User Manual airCUE-XM8 www.cuesystem.com... -
Page 6: Specifications
Enclosure........Wood - stainless steel Dimensions (WxHxD) ....280 mm (11”) x 200 mm (7.9”) x 34 mm (1.3”) Weight........2 kg / 4.4 lb Supplied accessories....Charger USB Cable Available accessories ....Docking Station User Manual airCUE-XM8 www.cuesystem.com Page 6 of 41... -
Page 7: Transport And Storage
Transport and Storage To avoid battery damage it is absolutely necessary fully charge battery and switch off airCUE-XM8 by inside CF Card Slot (see section 7.1) before transport and storage. User Manual airCUE-XM8 www.cuesystem.com Page 7 of 41... -
Page 8: Physical Description
Press the pushbutton again to exit from the Windows environment and return to the Launch Screen. RIGHT Pushbutton Pressing the pushbutton shows/hides an input panel (keyboard). Built-in Speakers Sound alarms and playback sound recordings. Built-in Microphone The microphone allows you to record voice messages. User Manual airCUE-XM8 www.cuesystem.com Page 8 of 41... -
Page 9: Rear Panel
Headphone Connector Connector Power Supply Connector This connector allows you to connect airCUE-XM8 to the external power with the supplied AC adapter. It is used for charging of the battery without Docking Station. Headphone Connector Lets you connect standard headphones. -
Page 10: Bottom Panel
Use the stylus to tap or double tap on an application icon or to select items on the menu. The stylus is also used to type on the Input Panel (keyboard). Use of other pointers could damage our screen. When stylus is not used you can place it in the storage slot located on the top right corner of airCUE-XM8. Stylus User Manual airCUE-XM8 www.cuesystem.com... -
Page 11: Setup And Using
Switch On The airCUE-XM8 is supplied with On/Off switch turned off. This is due to the longevity of battery during the transportation and storage. The On/Off switch is located in the space of CF Card Slot – see the following picture. -
Page 12: Autorestore
7.4. Autorestore The airCUE-XM8 has preinstalled Backup Manager for backup and restore operation. When the battery was fully discharged, connect power supply and switch power button on to restore airCUE-XM8 into last Backup state. Autorestore restores • Wi-Fi Card driver •... -
Page 13: Launch Screen
Launch Screen Overview Now airCUE-XM8 is ready to use and the initial Launch Screen will appear. The Launch Screen enables to run Control Application dedicated to control and prepared by CUE programming tools; and also Embedded Applications, which are the standard Windows CE .NET applications. -
Page 14: Remote Control
Backup/Restore This button runs a Backup/Restore application Backup Manager. Settings This button runs an application for setting your airCUE-XM8. Remote Control Runs an active remote control application programmed in Cue Design Director. User Manual airCUE-XM8 www.cuesystem.com Page 14 of 41... -
Page 15: Backup/Restore
7.6. Backup/Restore airCUE-XM8 is ready to provide full backup and restore operation to prevent loss of any data and system settings. It is necessary to make Backup operation after each system settings changes such as IP settings, Wireless network configuration etc. Only in this case the airCUE-XM8 will be restored to proper state. -
Page 16: Settings
Configuration page Identification This page is used for setting the identity of a specific airCUE-XM8 panel. Each airCUE-XM8 can be identified by a unique identification name. Unique names are most useful in applications requiring more than one airCUE-XM8. This enables programmers and installers to reference touch panel with a logical, user friendly name, like “boardroom,”... - Page 17 IP settings This page will display the communication parameters the airCUE-XM8 given: a physical address (MAC), a current IP address and a current default gateway. User Manual airCUE-XM8 www.cuesystem.com Page 17 of 41...
- Page 18 This page will display DNS server addresses the airCUE-XM8 given: a current primary DNS server and a current secondary DNS server. User Manual airCUE-XM8 www.cuesystem.com Page 18 of 41...
- Page 19 Pushbuttons This page is used for setting front panel pushbuttons function. User Manual airCUE-XM8 www.cuesystem.com Page 19 of 41...
- Page 20 Date and time page This page is used for setting the time clock on your airCUE-XM8. The current date, time, and time zone are shown on the Current time line. The applicable boxes can be selected to enter changes to the date and time.
- Page 21 applications.
- Page 22 File storage page The airCUE-XM8’s generous memory can be used as an auxiliary file storage device. This is helpful in archiving electronic manuals, PDF and other support documentation. File storage is managed via the file storage page. A list of existing files, folders, and their properties are shown. To delete a file or a folder, click the Delete button on the corresponding line.
- Page 23 System page Firmware This page is used for updating the airCUE-XM8 firmware. The Current version of firmware is shown. To upload new firmware, select the desired version, and click the Upload button. User Manual airCUE-XM8 www.cuesystem.com Page 23 of 41...
- Page 24 Information The page shows basic information about your airCUE-XM8’s hardware. The CPU type, CPU frequency, and the Flash and RAM memory sizes, are shown. User Manual airCUE-XM8 www.cuesystem.com Page 24 of 41...
- Page 25 (an error message will generate if the confirmation does not match, in which case you should reenter your password again in both boxes). Finally, the new password is implemented by clicking the Apply button. User Manual airCUE-XM8 www.cuesystem.com Page 25 of 41...
- Page 26 Reset page The page enables to restart the airCUE-XM8 by clicking the Reset button. User Manual airCUE-XM8 www.cuesystem.com Page 26 of 41...
- Page 27 License page The page shows a software and firmware license. User Manual airCUE-XM8 www.cuesystem.com Page 27 of 41...
-
Page 28: Factory Default Configuration
To use different network settings use standard Windows CE network configuration. 7.10. User Control Application User control application is dedicated to control and is programmed by Cue Director programming tools. It is composed of elements for AV, lighting, heating, and air conditioning control etc. based on the actual application. -
Page 29: Embedded Applications
7.11. Embedded Applications airCUE-XM8 is supplied with the following embedded applications. • Internet Explorer • Inbox (e-mail client) • WordPad • Excel Viewer • PowerPoint Viewer • Image Viewer • Media Player • PDF Viewer • PIM Synchronization All of these applications can be run from the initial Launch Screen or from a standard Windows CE desktop. -
Page 30: Default Settings
Default Settings 8.1. airCUE-XM8 Network Setup Activate Taskbar Tap the screen on bottom gray area of screen. The Taskbar will fade up. Wireless Network Settings Activate Taskbar and double-tap the Network icon on the Taskbar. The Wi-Fi adapter dialog box will be displayed. - Page 31 Connect to the Selected Network This window lists all wireless networks available to the airCUE-XM8. You can select a network from the list. Select item and tap Connect or click on Add New... and fill the Network Name (SSID). User Manual airCUE-XM8 www.cuesystem.com...
- Page 32 Activate Taskbar and select Start – Settings – Network and Dial-up Connections the window with active network adapter will be displayed. Double-tap icon with wireless connection (it depends on used driver – WLANNDS1, PRISM1 etc.) the dialog box with IP settings will be displayed. Name Servers User Manual airCUE-XM8 www.cuesystem.com Page 32 of 41...
-
Page 33: Charging
Charging 9.1. Standard Charging The charger including the power cord is supplied with the unit. The charger can be directly connected to airCUE-XM8 or Docking station. The direct charging is show at the picture bellow. airCUE-XM8 Power Supply Power supply... -
Page 34: Optional Docking Station
3. Install cover back and screw all screws. 4. After connecting the charger you may insert the airCUE-XM8 into the Docking Station. The Docking Station can be used not just as a charging stand but also as an inclined desktop stand. -
Page 35: Software And Firmware License
DISPOSE OF ALL WRITTEN MATERIALS IN YOUR POSSESSION REGARDING THE SOFTWARE. License Grant: CUE grants to You, as an individual, a license to install and use one (1) copy of the Software on a single computer at a time; provided, however, that You may make copies of the Software solely for Your development of applications for CUE hardware and demonstration versions of such applications. -
Page 36: Warranty Conditions
CUE, a.s. provides warranty for all CUE products for a period of 3 years from the day of purchase. The provided warranty for touch screens is 2 years from the day of purchase. CUE accepts reclamation of 5 not properly working dots and more (2 dots join – 1 counts). -
Page 37: Ce Declaration Of Conformity
12. CE Declaration of Conformity We, the producer CUE, a.s., K Nouzovu 6, Praha 4, Czech Republic acknowledge our sole responsibility, that the product including accessories Kind of Equipment: Remote Control System Type Designation: (in alphabetic order) airCUE-XM8 PEF150 CS0254-W, CS0254-O, CS0254-M... - Page 38 EN50082-1 (IEC801-2), IEC65(CO)39, DIN VDE 0839 part 82-1, DIN VDE 0843 part 4, IEC801-4, EN50081-1 EN55022 class B, DIN VDE 0839 part 81-1, EN55014, EN55011. Jaroslav Dibitanzl Member of Board of Directors User Manual airCUE-XM8 www.cuesystem.com Page 38 of 41...
-
Page 39: Fcc
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help. User Manual airCUE-XM8 www.cuesystem.com Page 39 of 41... -
Page 40: Cleaning The Touch Panel
Turn the touch panel off. Spray a small amount of the cleaning solution onto one of the cloths. Clean the touch panel overlay with the damp cloth. Wipe the touch panel overlay with the dry cloth. User Manual airCUE-XM8 www.cuesystem.com Page 40 of 41... - Page 41 Notes User Manual airCUE-XM8 www.cuesystem.com Page 41 of 41...
