PROGRESSIVE DYNAMICS, INC.
POWER CONVERTER LIMITED WARRANTY
I.
LIMITED WARRANTY: Progressive Dynamics, Inc. warrants its power converter to be free from defects
in material or workmanship under normal use and service; and limits the remedies to repair or replacement.
II. DURATION: This warranty shall extend for a period of two years from the original date of purchase, and
is valid only within the continental limits of the United States and Canada.
III. WARRANTY EXCLUSIONS: This warranty specifically does not apply to:
A. Any power converter which has been repaired or altered in any way by an unauthorized person or service
station;
B. Damage caused by excessive input voltage, misuse, negligence or accident; or an external force;
C. Any power converter which has been connected, installed or adjusted or used other than in accordance with
the instructions furnished, or has had the serial number altered, defaced or removed;
D. Cost of all services performed in removing and re-installing the power converter; and
E. ANY LOST PROFITS, LOST SAVINGS, LOSS OF USE OF ENJOYMENT OR OTHER INCIDENTAL
DAMAGES ARISING OUT OF THE USE OF, OR INABILITY TO USE, THE PRODUCT. THIS
INCLUDES DAMAGES TO PROPERTY AND, TO THE EXTENT PERMITTED BY LAW, DAMAGES
FOR PERSONAL INJURY. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
IV. PROOF OF PURCHASE: A warranty claim must be accompanied by proof of the date of purchase.
V. CLAIM PROCEDURE: Upon discovery of any defect, Progressive Dynamics, Inc. shall be supplied the
following information at the address listed below:
A.
B.
C.
D.
E.
Upon determination that a warranty claim exists (a defect in material or workmanship occurring under normal
use and service,) the power converter shall be shipped postage prepaid to Progressive Dynamics, Inc. together
with proof of purchase. The power converter will be repaired or replaced and returned postage prepaid.
PD9200 SERIES
OWNERS MANUAL
Name and address of the claimant;
Name and model of the power converter;
Name, year and model of the recreational vehicle in which the power converter
was installed;
Date of purchase; and
Complete description of the claimed defect.
Progressive Dynamics Inc.
507 Industrial Rd.
Marshall, MI 49068
269.781.4241, Fax 269.781.7802
service@progressivedyn.com
www.progressivedyn.com
TM
109821D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD9200 SERIES and is the answer not in the manual?

Questions and answers

Summary of Contents for Progressive Dynamics PD9200 SERIES

  • Page 1 PD9200 SERIES OWNERS MANUAL PROGRESSIVE DYNAMICS, INC. POWER CONVERTER LIMITED WARRANTY LIMITED WARRANTY: Progressive Dynamics, Inc. warrants its power converter to be free from defects in material or workmanship under normal use and service; and limits the remedies to repair or replacement.
  • Page 2 FEATURES INTEGRATED CHARGE WIZARD ... The INTELI-POWER 9200 Power Converter is the intelligent way to ® charge your RV battery. The built-in Charge Wizard microprocessor constantly monitors the battery voltage then automatically adjusts the converter output voltage to provide the proper charging voltage for fast recharges and long-term maintenance.
  • Page 3: General Information

    GENERAL INFORMATION The INTELI-POWER 9200 series 120 VAC to 12 VDC power converters are state-of-the-art electronic converter / battery chargers. The INTELI-POWER 9200's are UL and CUL (Canadian) listed. Their compact size and quiet operation gives greater flexibility in selecting the mounting location for either OEM installation or after market replacement.
  • Page 4: General Operation

    GENERAL OPERATION The INTELI-POWER 9200 series will supply "clean" nominal 13.6 VDC (Normal Mode) power from input voltages that range from 90-130 VAC. The INTELI-POWER 9200 series of converters are primarily designed for use with a battery, however, the output of the INTELI-POWER 9200 converters are a regulated, filtered D.C.
  • Page 5: Installation Instructions

    If a REMOTE PENDANT was not provided with you INTELI-POWER 9200 Series Converter/Charger, you can purchase one from your Local RV Dealer or on-line at www.Progressivedyn.com. INSTALLATION INSTRUCTIONS Horizontal mounting of the INTELI-POWER 9200, is recommended although it can be mounted in any position that provides unobstructed ventilation to the fan and vent holes.
  • Page 6: Input/Output Specifications

    INPUT/OUTPUT SPECIFICATIONS (Specifications subject to change without notice) PD9230 PD9240 PD9245 Input: 105-130 VAC 60 Hz Input: 105-130 VAC 60 Hz Input: 105-130 VAC 60 Hz 500 Watts 600 Watts 725 Watts Output: 13.6 VDC, 30 Amps Output: 13.6 VDC, 40 Amps Output: 13.6 VDC, 45 Amps Dimensions: 4.5H x 8.25L x 7.25W Dimensions: 4.5H x 8.25L x 7.25W...
  • Page 7 PD9200 Série MANUEL DU PROPRIÉTAIRES PROGRESSIVE DYNAMICS, INC. GARANTIE LIMITÉ DU CONVERTISSEUR GARANTIE LIMITÉE: Progressive Dynamics, Inc. justifie son convertisseur de puissance pour être exempt de tous défauts dans le matériel ou l'exécution sous une utilisation et un entretien spécifique au produit;...
  • Page 8: Informations Générales

    DISPOSITIFS MAGICIEN INTÉGRÉ DE CHARGE... Le convertisseur de puissance d'INTELI-POWER 9200 est la manière intelligente de charger votre batterie de RV. Le magicien intégré de charge que le microprocesseur surveille constamment la tension de batterie ajuste alors automatiquement la tension de rendement de convertisseur pour fournir la tension de charge appropriée pour les recharges rapides et l'entretien à long terme. REMPLISSAGE MULTIPLE DE LA BATTERIE...
  • Page 9 14.4 Volts (Mode De Poussée) A renvoyé la batterie à 90% de la pleine charge en approximativement 3 heures. La batterie a atteint la pleine charge en approximativement 11 heures. 13.6 Volts (Mode De normale) Requis 40 heures pour renvoyer la batterie à 90% de la pleine charge et 78 heures à la pleine charge d'extension.
  • Page 10: Instructions D'installation

    "on" de lumière - Indique que le convertisseur est en mode de poussée et la tension de rendement est de 14.4 volts continu pour recharger rapidement la batterie jusqu'à 90% de la pleine charge. Des clignotements de lumière rapidement (toutes les 2 ou 3 secondes) - indique que le convertisseur est en "copie normale" et la tension de rendement est 13.6VDC.
  • Page 11: Guide De Dépannage

    LES CONVERTISSEURS D'CINTELI-POWER 9200 NE SONT PAS IMPERMÉABLE TEMPS FORTEMENT OU CONÇU POUR LE SUPPORT D’EMPLACEMENT HUMIDE. ILS DOIVENT ÊTRE PROTÉGÉS CONTRE LE CONTACT DIRECT AVEC DE L'EAU. PENDANT LE PROCESSUS DE FABRICATION ÉVITEZ L'INTRODUCTION DES MATÉRIAUX ÉTRANGERS DANS LE CAS CAR CECI POURRAIT CAUSER UN DÉFAUT DE FONCTIONNEMENT DU CONVERTISSEUR.
  • Page 12 CARACTÉRISTIQUES D'CENTRÉE_SORTIE PD9230 PD9240 PD9245 Entrée: 105-130 VAC 60 Hz Entrée: 105-130 VAC 60 Hz Entrée: 105-130 VAC 60 Hz 500 Watts 600 Watts 725 Watts Sortie: 13.6 VDC, 30 Ampères Sortie: 13.6 VDC, 40 Ampères Sortie: 13.6 VDC, 45 Ampères Dimensions: 4.5H x 8.25L x 7.25W Dimensions: 4.5H x 8.25L x 7.25W Dimensions: 4.5H x 8.25L x 7.25W...
