Summary of Contents for Adam S6A Mk2
- Page 1 S6A Mk2 Operation manual English...
- Page 2 We request that you read these sections carefully to ensure an easy set up and to prevent potential problems. The S6A Mk2 is suitable for main monitoring. It is perfectly suited for large control rooms, post-production suites, etc.—an ideal tool for situations where a combination of no-compromise sound reproduction and high SPL regions is required.
-
Page 3: Table Of Contents
Table of contents Quick Start ........4 Important Information ....4 Quick Start S6A Mk2 .....4 Speaker Placement ......5 General Recommendations ....5 Stereo Setup ........5 Surround Setup ......5 Controls/Speaker Adjustement ..6-7 The front (control) panel ....6 Input gain ........6 X-Curve Filter .........6 Driver gains ........7... -
Page 4: Quick Start
Break-in time: Please note that the loudspeakers will need a few days to achieve optimum sonic performance. Quick start S6A Mk2 Before connecting the loudspeakers to your audio components and the power source make sure that both the loudspeakers and your audio system is switched off! Set all level controls fully counterclockwise. -
Page 5: Speaker Placement
Speaker Placement General recommendations/advises Direct sound ways: There should be no obstacles in the way from the monitor to your ears. You should be able to see the speakers completely. Alignement: The loudspeakers should be aligned with the listener’s position. Nearby objects: Please note that vibrating parts of nearby objects can mask the sound. -
Page 6: Controls/Speaker Adjustement
The X-curve engages a 3 dB per octave roll-off above 2 kHz. The S6A Mk2 and S7A Mk2 have a switch located below the input selector that activates this filter, eliminating the need for external processing... -
Page 7: Driver Gains
Controls/Speaker Adjustment Driver gains Whereas the ‘Input Gain’ raises or lowers the overall input sensitivity up to +/-10 dB, the ‘Driver Gains’ work only within the corresponding frequency range, raising or lowering from +/-2 to +/-6 dB. High / low shelving The other two controls operate in a different manner. -
Page 8: Troubleshooting
Troubleshooting All ADAM products are designed and manufactured to the highest quality standards. However, if any problems with your speaker occur, we recommend to proceed as follows: Problem: The LED shows normal operation (green) but there is either no or only a distorted audio signal. -
Page 9: Maintenance
Experience has shown that it is very difficult to avoid damage if you have to send them with- out these. ADAM Audio can not be held responsible for damages due to im- proper packaging. -
Page 10: Eu Declaration Of Conformity
EU Declaration of Conformity ADAM Audio GmbH whose registered office is situated at Lobeckstr. 36, 10969 Berlin, Germany declare under our sole responsibility that the product: S6A Mk2 complies with the EU Electro-Magnetic Compatibility (EMC) Directive 89/336/EEC, in pursuance of which the following standards have been ap-... -
Page 11: Limited Warranty
Warranty ADAM Audio GmbH provides a two year limited warranty for this product. If anything goes wrong with this product due to manufacturing defects, ADAM Audio and its national distributors will provide repair free of charge (exclu- sions may apply) and replacement parts. -
Page 12: Safety Instructions
Do not open the loudspeaker. There are no user-serviceable parts inside. In case of a problem, please contact either your ADAM dealer or us. We are happy to help. Always refer servicing to qualified personnel and never attempt to repair this product yourself. -
Page 13: Technical Data
Technical Data ADAM S6A Mk2 - active 4-ways bass reflex loudspeaker Woofer/Subwoofer Basket ø 7“/12“ HexaCone® Voice coil ø 1.5“/2.5“ ART Tweeter Diaphragm area 71 cm Equivalent diaphragm ø 9,5 cm Speed transformation ratio Diaphragm weight 0,17 g ART Midrange... - Page 14 +49 30-863 00 97-0 fax: +49 30-863 00 97-7 email: info@adam-audio.com ADAM Audio USA 31312 Via Colinas Unit 108 | Westlake Village | CA, 91362 phone: +1 818-991 3800 fax: +1-818-991 3808 email: usa@adam-audio.com S6A Mk2 Manual www.adam-audio.com Version 09.2008 English...
