Generac Power Systems 00919-0 Owner's Manual page 29

Generac NP-50LPG Recreational Vehicle Generator
REPAIR PARTS — ENGINE ACCESSORIES
ITEM PART NO. QTY. DESCRIPTION
1 90896 1
2 91039 1
3 68527 2
4 72347 1
5 89228 1
6 A2775A 1
7 90970 1
8 73108C 1
9 91204 1
10 59635 2
11 66476 2
12 92695 2
13 73111 1
14 81646 1
15 73104-B 1
16 78609 2
17 20139 1
18 91554 1
91554B 1
MANIFOLD, INTAKE
GASKET, MANIFOLD/HEAD
BOLT, HEX HD. CAPSCR. &
LOCK WASHER-M6-1.0 x 20
SPARK PLUG, CHAMPION
#RC12YC
GASKET, CARB./MANIFOLD
L/P CARBURETOR
GASKET, CARB./AIR FILTER
BASE, AIR FILTER
PLATE, CARB. SHIELD
SCREW, PLASTITE #8 x .37"
BOLT, HEX HD. CAPSCR., &
LOCK WASHER-M6 x 12 LG
BOLT, CARB. MOUNT 80 LG
FILTER, AIR
PRE-CLEANER, AIR FILTER
COVER, AIR FILTER
BOLT, AIR FILTER COVER
SNAP BUSHING
DECAL, A/C DATA NP-50G
(360 ENGINE ONLY)
DECAL, A/C DATA NP-50G
(410 ENGINE ONLY)
R e c r e a t i o n a l V e h i c l e G e n e r a t o r
ITEM PART NO. QTY. DESCRIPTION
39 92164
40 83512
41 83503
42 91916
43 83532
44 86681
45 91638
46 91633
47 92586
48 91161
49 91636
50 91637
51 91649
52 91645
53 22473
54 22097
55 A4009
56 A7029
29
Drawing No. 95866
1 ASSEMBLY, GOV. SPRING
ADJ. BRACKET
2 BOLT, TAPTITE M8 x 15 LG
1 NUT, LOCKING M5- 0.8
1 LEVER, GOVERNOR ARM
1 BOLT, HEX HD. WASHER
/LOCK WASHER-M6 x 30
1 NUT, M6 SPECIAL
1 SPRING, GOVERNOR
1 BELLCRANK, GOV. RODS
2 WASHER, FELT
1 BOLT, SHOULDER M6 x 15
1 ROD, LINKAGE GOV.
LEVER-BELLCRANK
1 ROD, LINKAGE BELLCRANK
-CARB.
2 SPRING, A/L GOV. LEVER-
BELLCRANK
1 BREATHER TUBE
4 M6 FLAT WASHER
2 M6 LOCK WASHER
1 SPRING WASHER
1 NYLON WASHER, .31 X .26
X .13
