Set Exercise Time Switch; System Ready Led - Generac Power Systems QuietSource 005031-2 Owner's Manual

Condition
Generator Switch is
in the OFF Mode.
System Ready for
Automatic Start
Generator Switch is
in the MANUAL Mode
Weekly Exerciser
is not set
Battery Voltage <12V
for >1 minute
Battery Voltage <6V
Unit Shutdown due
to Low Oil Pressure
Unit Shutdown due to
High Coolant Temperature
or Low Coolant Level
Unit Shutdown due
to Engine Overspeed
Unit Failed to Start
during it's Crank Cycle
Utility Voltage is
<45% of Nominal
Engine Speed Signal Fault
Control Board is
in GTS Mode
3.2.3 15 AMP FUSE
This fuse protects the control console's DC control
circuit against electrical overload and is located inside
the control panel. If the fuse has melted open because
of an overload, engine cranking and startup cannot
occur. If the fuse needs to be replaced, use only an
identical 15-amp replacement fuse (type ATO).
3.2.4 5 AMP FUSE
This fuse protects the battery charger against electri-
cal overload and is located inside the control panel.
If the fuse needs to be replaced, use only an identical
5-amp replacement fuse (type ATO).
This fuse will not remove the + battery input
power from the PCB when it opens. This means
the exercise timer will not be reset.
14
Section 3 - Operation
Liquid-cooled 25 kW Generators
System Low
Ready (Green) Bat (Red)
OFF X
ON X
OFF X
X Flashing
(-----------------------------------1 sec rate---------------------------------------)
X ON
(Non-latching)
X ON
OFF X
OFF X
OFF X
OFF X
Flashing X
1 sec rate
OFF X
OFF X
X = indicates that the LED can be ON or OFF depending on the operating conditions.
NOTE:
Low High
Oil (Red) Temp (Red)
OFF OFF
OFF OFF
OFF OFF
Flashing Flashing
ON
ON
The five RED LED's will turn on one at a time

3.2.5 SET EXERCISE TIME SWITCH

This switch allows programming the generator to
start and exercise automatically. "See Weekly Exercise
Cycle" (see Figure 3.3 and Section 3.7).

3.2.6 SYSTEM READY LED

The System Ready LED (green) has two main pur-
poses. First, the LED will be ON when the AUTO/
OFF/MANUAL switch is in the AUTO position, utility
is present, and there are no system alarms. This ON
state indicates the system is fully ready for automatic
operation.
The system ready LED will be OFF when the switch
is in the MANUAL or OFF positions.
The system ready LED is also used to indicate the
presence of utility sensing at the PCB when the switch
is either in the AUTO or MANUAL modes. The LED
will flash at the rate of 1/2 second on, 1/2 second off
if the utility sensing level is below the transfer back
threshold.
Over Over
Speed (Red) Crank (Red)
OFF OFF
OFF OFF
OFF OFF
Flashing Flashing
ON
ON
Flashing
Switch Position
Manual Auto Off
O
O
O
O O O
O O O
O O
O O
O O
O O
O O
O O
O O
O O O
