SYSTEM SPECIFICATIONS
7060B
Free field frequency response 19 Hz...85 Hz
(+/- 3 dB) LFE 85/120 Hz
Maximum short term sine wave
SPL output averaged from
30 to 85 Hz, measured in
half space at 1 meter ≥ 108 dB SPL
Maximum peak SPL output with
random pink noise, measured
in half space at 1 meter ≥ 113 dB SPL
Self generated noise level in
free field @ 1 m on axis
(A-weighted) ≤ 15 dB
Harmonic distortion @ 90 dB SPL
at @ 1 m on axis in half space 30 ... 85 Hz
2nd ≤ 3 %
3rd ≤ 2 %
Driver, magnetically shielded 250 mm (10")
Weight 26 kg (57 lbs)
Dimensions
Height 527 mm (20 3/4")
Width 462 mm (18 3/16")
Depth 363 mm (14 5/16")
CROSSOVER SECTION
7060B
Subsonic filter
(18 dB/octave) below 19 Hz
Crossover frequency,
(sub/main channels) 85 Hz
LFE cutoff Hz 85 Hz/120 Hz selectable
Crossover slopes
Lowpass 36 dB/octave
Highpass 12 dB/octave
Midband rejection >400 Hz ≥ 50 dB
Bass Roll-Off control operating From 0 to –6 dB
range in 2 dB steps @ 20 Hz
Phase matching control From 0 to 270
in 90° steps @ 85 Hz
Genelec Document D0032R001b. Copyright Genelec Oy 3.2006. All data subject to change without prior notice
7070A 7071A
19 Hz...85 Hz 19 Hz...85 Hz
LFE 85/120 Hz LFE 85/120 Hz
≥ 112 dB SPL ≥ 118 dB SPL
≥ 117 dB SPL ≥ 123 dB SPL
@ 95 dB SPL @ 100 dB SPL
30 ... 85 Hz 30 ... 85 Hz
≤ 3 % ≤ 3 %
≤ 3 % ≤ 3 %
305 mm (12") 2 x 305 mm (12")
50 kg (110 lbs) 81 kg (178 lbs)
625 mm (24 5/8") 755 mm (29 3/4")
555 mm (21 7/8") 803 mm (31 5/8")
490 mm (19 5/16") 490 mm (19 5/16")
7070A 7071A
19 Hz 19 Hz
From 0 to –6 dB From 0 to –6 dB
@ 20 Hz @ 20 Hz
