Data Sheet
Fujitsu CELSIUS R920 Workstation
Fujitsu recommends Windows 8 Pro.
Data Sheet
Fujitsu CELSIUS R920
Workstation
Uncompromising Workstation Performance for Extreme Requirements
Fujitsu´s most performing workstation the CELSIUS R920 achieving first-class benchmark results
is designed to surpass all your expectations. This reliable, high-end dual processor workstation is
individually configurable for the most power hungry, 24/7 operating environments. Best-in-class
noise emissions of just 21 dB, and comprehensive ISV certifications that ensure smooth application
operation, enhance your productivity. The convenient cold plug access at front simplifies subsequent
expansion.
Performance
Higher productivity
High performance multi-core processors, next generation graphics subsystems, quad-channel
memory technology and high-speed hard disk drives
Ergonomics
Noise-reduced system engineered in Germany
Optimized thermal management, low-noise chassis and silent fans
Reliability
System stability for the complete lifecycle
High product standards thanks to top-quality components and comprehensive testing in certified
in-house laboratories for 24/7 operation
Certification of workstation applications
Stability, compatibility and performance for the main workstation applications
Comprehensive support for ISV applications and ease of integration into existing IT networks
Expandability
Excellent expandability for future demands
Increased memory capacities of up to 512 GB
Page 1 / 9
www.fujitsu.com/fts/CELSIUS

Advertisement

loading

Summary of Contents for Fujitsu CELSIUS R920

  • Page 1 Workstation Uncompromising Workstation Performance for Extreme Requirements Fujitsu´s most performing workstation the CELSIUS R920 achieving first-class benchmark results is designed to surpass all your expectations. This reliable, high-end dual processor workstation is individually configurable for the most power hungry, 24/7 operating environments. Best-in-class noise emissions of just 21 dB, and comprehensive ISV certifications that ensure smooth application operation, enhance your productivity.
  • Page 2 Data Sheet Fujitsu CELSIUS R920 Workstation Fujitsu recommends Windows 8 Pro. Components Processor Intel® Xeon® processor E5-2690 (8 Cores / 16 Threads, 2.90 GHz, up to 3.8 GHz, 20 MB, 8.0 GT/s) Intel® Xeon® processor E5-2687W (8 Cores / 16 Threads, 3.10 GHz, up to 3.8 GHz, 20 MB, 8.0 GT/s) Intel®...
  • Page 3 Data Sheet Fujitsu CELSIUS R920 Workstation Fujitsu recommends Windows 8 Pro. Graphics Ultra-high-end 3D: NVIDIA® Quadro® K5000, 4 GB, 1536 cores, PCIe x16, 1x Dual Link DVI-I, DVI-D, 2x DisplayPort High-end 3D: AMD FirePro™ W8000, 4 GB, 1792 stream processors, PCIe x16, 4 x DisplayPort High-end 3D: AMD FirePro™...
  • Page 4: Main Board

    Data Sheet Fujitsu CELSIUS R920 Workstation Fujitsu recommends Windows 8 Pro. SCSI / SAS Controller RAID Contr BBU Upgrade for RAID 5/6 Ctrl RAID 5/6 Ctrl. 6 Gbit/s 8 ports ext. 512 MB Cache RAID 0/1 Ctrl. 6 Gbit/s 8 ports ext.
  • Page 5 Data Sheet Fujitsu CELSIUS R920 Workstation Fujitsu recommends Windows 8 Pro. Interfaces Mouse / Keyboard (PS/2) 1 / 1 Ethernet (RJ-45) eSATA Interface Module notes Anytime USB charge functionality Drive bays Drive bays total 2.5-inch bays 3.5-inch internal bays 3.5-inch external bays 5.25-inch external bays...
  • Page 6 Data Sheet Fujitsu CELSIUS R920 Workstation Fujitsu recommends Windows 8 Pro. Compliance Product CELSIUS R920 CELSIUS R920 Power Model ETNA_L-D3118 Germany depending on configuration USA/Canada cCSAus FCC Class B FCC Class A (in combination with InfiniBand add on card) Global RoHS (EU &...
  • Page 7: Recommended Accessories

    Service Weblink http://www.fujitsu.com/fts/services/support Recommended Accessories FUTRO L420 Fujitsu FUTRO L420 meets a multitude of user and business needs. It is Order Code: designed to handle standard office tasks and demanding, high-graphics S26361-K1062-V200 applications over PCoIP. Dual-monitoring enables you to increase your productivity.
  • Page 8 Fujitsu P Line widescreen S26361-K1428-V140 display. Mouse M440 ECO Fujitsu Mouse M440 ECO is made from 100% bio material and has a Order Code: completely PVC free cable. The elegant M440 ECO works on nearly every S26381-K450-L200 surface and follows all your hand movements smoothly and precisely.
  • Page 9: More Information

    Fujitsu CELSIUS R920 Workstation More information Fujitsu OPTIMIZATION Services More information Copyrights In addition to Fujitsu CELSIUS R920, Fujitsu Learn more about Fujitsu CELSIUS All rights reserved, including intellectual provides a range of platform solutions. They R920, please contact your Fujitsu sales property rights.
