Summary of Contents for Electrolux EFT611
- Page 1 Gebrauchsanweisung , Notice d'utilisation et d'installation EFT 611 Installatie- en gebruiksaanwijzing , User manual...
-
Page 2: Table Of Contents
Contents Safety warnings for the installer for the user Description of the appliance Extractor version Filter Version Control Panel Correct ventilation If the hood does not function Before you make contact to service Service and spare parts Maintenance and care Cleaning Metal grease filter Open the metal grease filter... -
Page 3: Safety Warnings
Safety warnings for the installer aforementioned measures. • When the hood is used in its extractor function, • When used as an extractor unit, the hood must the following rules must be followed to obtain be fitted with a 120mm diameter hose. optimal operation: •... -
Page 4: Description Of The Appliance
Description of the appliance • The hood is supplied as an extractor unit and can also be used with a filtering function by fitting one charcoal filter (special accessory). • You will need original ELECTROLUX charcoal filter for this function (see Special Accessories). Extractor version •... -
Page 5: Control Panel
Control Panel • The hood is fitted with one motor having several speed. Turn the hood on a few minutes before you start cooking, you will then get an under pressure in the kitchen. The hood should be left on after cooking for about 15 minutes or until all the odours have disappeared. -
Page 6: Maintenance And Care
Maintenance and care The hood must always be disconnected from the electricity supply before beginning any maintenance work. Cleaning Warning • Warning: always disconnect the hood from the • Failure to observe the instructions on cleaning mains power supply before cleaning it. the unit and changing the filters will cause a fire Never insert pointed objects in the motor’s hazard. -
Page 7: Charcoal Filter
Charcoal filter • The charcoal filter should only be used if you want to use the hood in its filtering function. • To do this you will need an original ELECTROLUX charcoal filter (see special accessories). • Cleaning/replacing the carbon filter Unlike other carbon filters, the LONGLIFE charcoal filter can be cleaned and reactivated. -
Page 8: Technical Specifications
Technical Specifications Dimensions (cm) Height 16,3 Width 59,9 Depth 53,5 Lighting 2x40 W Grease filter power absorption 200 W We reserve the right to generate constructive and chromatic modifications as required by technological growth. Special accessories Carchoal filter KF 12/13 E-Nr. -
Page 9: Mounting Accessories Included
Installation Mounting accessories included 3 wood-screws 5 x 45 mm 3 wall plugs Ø 8 mm 1 metal screws 2,9 x 9,5 mm 4 metal screws 4,2 x 35 mm 1 allen spanner for TORX screws 1 flange 1 cap Wall unit mounting - Fig. - Page 12 LI1ZPA Ed.06/02...
