- Page 1 MIRO CUBE™ DESIGNED BY THE BLACK TANK USER’S MANUAL...
-
Page 3: Table Of Contents
Table of Contents Your MIRO CUBE™ Product Description..................5 What’s In the Box..................... 7 MIRO CUBE™ Interface.................. 8 MIRO CUBE™ Series MIRO CUBE™ 4C....................9 MIRO CUBE™ WNC..................10 MIRO CUBE™ UV....................11 MIRO CUBE™ Modes DMX Mode......................12 Manual Mode....................16 Color Wash Mode.................... - Page 4 Table of Contents Linear Arrays..................... 25 Safety Cables....................27 MIRO CUBE™ Support FCC Warning......................28 General Precautions..................29 Warning Messages..................30...
-
Page 5: Product Description
Product Description MIRO CUBE™ Rosco's innovative MIRO CUBE™ series of LED wash lights packs 48 watts outputting more than 3000 lumens into a compact and portable 4 inch cube! The sleek yet rugged, geometric design of the MIRO CUBE™ is perfectly at home in museums, on track light systems, in stores and lobbies or built into sets, truss and lighting rigs of all styles. - Page 6 Product Description Mounting these compact 4 inch cubes is limited only by the imagination of the installer. The novel through bolted yoke design allows units to be easily ganged into multi-unit strips and arrays for greater output and coverage. Weighing just 2-1/2 pounds, the MIRO CUBE™ can be attached to standard architectural lighting track using accessory track adapters.
-
Page 7: What's In The Box
What’s In the Box [1] MIRO CUBE™ [1] MIRO CUBE™ [2] Power Cable [3] Di user Pack... -
Page 8: Miro Cube™ Interface
MIRO CUBE™ Interface POWER LIGHT LCD DISPLAY P W R OK KEY MENU KEY M I R O C U B E M E N U D M X O U T P W R D E S I G N E D B Y T H E B L A C K T A N K DMX IN POWER PLUG DMX OUT... -
Page 9: Miro Cube™ 4C
MIRO CUBE™ 4C From walls to washes to uplighters, the MIRO CUBE™ 4C color mixing wash light o ers a designer maximum creativity in a tiny package. Using best in class RGBW quad color, multi channel chips, a gorgeous palette of saturated, mid-tone and pale tint colors can be dialed in at the touch of a button. -
Page 10: Miro Cube™ Wnc
MIRO CUBE™ WNC Size matters. But quality of light matters more! The MIRO CUBE WNC embodies what every lighting professional needs - A bright, tunable, beautiful white light. Using 12 high quality Cree XML 4W emitters, the MIRO WNC outputs 3100 lumens and can adjust from 2800K to 6500K. -
Page 11: Miro Cube™ Uv
MIRO CUBE™ UV Ideally suited for theme parks, night clubs, casinos, museums and stage applications, MIRO CUBE™ UV is the smallest, most a ordable high powered UV light available to lighting professionals. Drawing just 50 watts, it outperforms conventional long throw xtures using 5 times the power, weighing 10 times more, and which need an expensive lamp change every 1000 hours! The xture allows for... -
Page 12: Dmx Mode
DMX Mode In DMX mode, the unit is controlled by the data it receives on the ve pin DMX512 connectors located on the rear panel. The number of DMX channels required to control the xture is dependent on the factory setting in use (for example - Four Color MIRO CUBES™ use four DMX channels while One Color MIRO CUBES™... - Page 13 DMX Mode There are four user settings that can be adjusted in DMX mode. The current value of each setting is shown on the main screen. DMX001 8bit Fade0 Universe1 Temp=77F DMX Address: To change the DMX address, press MENU until “CHANGE DMX ADDRESS?”...
- Page 14 DMX Mode Universe1 or Universe2: The MIRO CUBE™ can be controlled via two unique DMX universes. DMX can be input on pins 2&3 (Universe1) or pins 4&5 (Universe2) via the 5 pin DMX connectors on the rear panel. This allows two complete universes of DMX to be transmitted on a single cable.
- Page 15 DMX Mode 8 bit or 16 bit DMX: The xture can run in either 8 bit or 16 bit DMX mode. In 8 bit mode, The MIRO CUBE™ accepts one DMX channel for each color. In 16 bit mode, two channels are required for each color. To change from 8 bit to 16 bit mode (or from 16 bit to 8 bit) press MENU until “SET TO 16BIT DMX?”...
-
Page 16: Manual Mode
Manual Mode WARNING: DO NOT CONNECT ANY MIRO CUBE™ IN MANUAL MODE TO ANY OTHER DMX SENDING DEVICE AS CONTENTION ON THE DMX512 INPUT WILL RESULT. In Manual Mode, the MIRO CUBE™ can be controlled directly from its rear panel without the need of a DMX console or a DMX control device. - Page 17 Manual Mode MIRO CUBE™ 4C Manual Mode allows you to set the color of your xture by adjusting the intensity of the LEDs using the rear panel and the LCD display. The current value of each setting is shown on the main screen.
- Page 18 Manual Mode MIRO CUBE™ WNC When set to Manuial Mode, the WNC allows you to set the color of your xture by adjusting the intensity of the LEDs using the rear panel and the LCD display. The current value of each setting is shown on the main screen.
- Page 19 Manual Mode MIRO CUBE™ UV Manual Mode can be used to adjust the brightness of a MIRO CUBE™ UV. The current brightness level is shown on the main screen. MANUAL Temp=77F Brightness = 255 To adjust color value, press the MENU key until “CHANGE BRIGHTNESS”...
-
Page 20: Color Wash Mode
Color Wash Mode Color wash is only available in MIRO CUBE™ 4C. In Color Wash mode, the MIRO CUBE™ automatically cycles through its entire saturated color spectrum by modulating the intensity of the red, green, and blue LEDs. COLOR WASH Temp=77F Time00:15 Offset=000... - Page 21 Color Wash Mode Wash Timer The wash timer determines how long it takes for the MIRO CUBE™ to complete an entire color cycle, and, by extension, the rate at which the colors change. Choose a short time for a rapid wash or a longer time for a slower wash.
- Page 22 Use the WASH OFFSET function to control the interaction between multiple MIRO CUBES™ in a Color Wash chain. The Wash O set determines the length of delay between each light, or how long it takes to “pass” a color from one light to the next. Set the Wash O set to “0”...
-
Page 23: Beam Angles
Beam Angles The beam angle can be easily adjusted using a holographic di using lm. Using a MIRO CUBE™ without a di using lm will create a narrow beam angle. WARNING: DISCONNECT THE POWER CABLE BEFORE REMOVING THUMBSCREWS. none 20˚ 40˚... -
Page 24: Changing The Di Using Film
Beam Angles To change the di using lm, unscrew the thumbscrews from the front panel and remove the acrylic panel. Replace the existing lm with the di user of your choice. Place the acrylic panel on top and secure it with four thumbscrews. NOTE: Custom beam angles available upon request. -
Page 25: Linear Arrays
Mounting WARNING: DISCONNECT THE POWER CABLE BEFORE MAKING ANY CONFIGURATION ADJUSTMENTS. Linear Arrays: The MIRO CUBE™ can be used as a single xture or in multi- xture arrays. NOTE: ADDITIONAL YOKES AND THREADED ROD ARE REQUIRED. To connect multiple xtures, remove the threaded rod by unscrewing one of the side knobs and using the other to pull the... - Page 26 Place the xtures next to each other. Attach a knob to one side of the double length threaded rod. Slide the double bracket around the xtures. Align the holes and position spacers on both sides of each xture (do not use multiple spacers between xtures). Insert the rod on the left side.
-
Page 27: Safety Cables
Safety Cables Single MIRO CUBES™ as well as arrays can be suspended from truss or other major support structures using 3rd party clamping devices. When used in suspended applications, a safety cable (provided by others) must be used as a positive retaining means between the main support structure and each brick using the "safety cable hole."... -
Page 28: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 29: General Precautions
General Precautions 1. The use of a safety cable is required when rigging the xture. 2. Before use, make sure all screws and safety points are secured. 3. Make sure the light is unplugged before removing rods, the enclosure or screws. 4. -
Page 30: Warning Messages
Warning Messages The Miro Cube™ has warning messages built in that will instruct you when an action needs to be taken. On startup, if a DMX signal is not present on the DMX connectors, and the xture is set to DMX mode, all of the LEDS will glow dimly. - Page 32 MIRO CUBE™ DESIGNED BY THE BLACK TANK...
