1.3. Jumpers & Connectors Description
Jumpers Description
CCMOS1 CMOS Clear
JP1 Auto-Reboot Switch
Connectors
ATX12V1
ATXPWR1
COM2
FAN1/FAN2
FAN4/FAN5
FPIO1
IDE0
J2/J3
J6
LPT1
USB1/USB2
VGA2
SI-1Ns
Description
4-pin ATX12V Power Connector
20-pin ATX12V Power Connector
External COM2 Bracket Connector
Fan Connector with monitoring Support
Fan Connector without monitoring Support
Front Panel Switch Headers
Hard Disk Drives Connector
DDR DIMM Slots
PCI 32bit/33MHz
Parallel Port Connector
Additional USB Ports Connectors
Additional VGA Port Connector
Chapter 1
Default Setting
Pins 1-2 (Normal)
Open (Enabled)
