Thank you for purchasing a Panasonic product.
This unit is an additional handset compatible with the following
series of Panasonic SIP Cordless Phone:
KX-TGP500/KX-TGP550
You must register this handset with your base unit before it can
be used. This installation manual describes only the steps
needed to register and begin using the handset. For further
details, please read the base unit's User Guide on the
Panasonic Web site at:
http://panasonic.net/pcc/support/sipphone/
Charge the batteries for about 6 hours before initial use.
Please read this installation manual before using the unit and
save it for future reference.
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Installation Manual
Additional Cordless Handset
KX-TPA50
Model No.
B02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic KX-TPA50 B02
Summary of Contents for Panasonic KX-TPA50 B02
- Page 1 Installation Manual Additional Cordless Handset KX-TPA50 Model No. Thank you for purchasing a Panasonic product. This unit is an additional handset compatible with the following series of Panasonic SIP Cordless Phone: KX-TGP500/KX-TGP550 You must register this handset with your base unit before it can be used.
-
Page 2: Accessory Information
/HHR-65AAAB Handset cover Belt clip/PNKE1029Z1 *1 Please read the replacement battery information section of the base unit’s User Guide on the Panasonic Web site. See page 1 for Panasonic URL. *2 The handset cover comes attached to the handset. Note: L Please read the additional/replacement accessory section of the base unit’s User Guide on the Panasonic Web site. -
Page 3: Battery Installation/Battery Charge
L Use the supplied rechargeable batteries. For replacement, we recommend using the Panasonic rechargeable batteries noted in the base unit’s User Guide on the Panasonic Web site. See page 1 for Panasonic URL. L Wipe the battery ends (S, T) with a dry cloth. -
Page 4: Registering A Handset To The Base Unit
L If an error tone sounds, or if _ is still displayed, register the handset according to the registering section of the base unit’s User Guide on the Panasonic Web site. See page 1 for Panasonic URL. – 4 –... -
Page 5: Wall Mounting
Belt clip N To attach N To remove Wall mounting Drive the screws (not supplied) into the wall. Mount the charger (A), then slide it down (B) and to the right (C) until it is secure. 25 mm Screws Note: L Make sure that the wall is strong enough to support the weight of the unit. -
Page 6: For Your Safety
L We recommend using the supplied batteries or additional/replacement batteries noted in the battery information section of the base unit’s User Guide on the Panasonic Web site. See page 1 for Panasonic URL. USE ONLY rechargeable Ni-MH batteries AAA (R03) size. -
Page 7: Other Information
L In the event of problems, you should contact your service provider in the first instance. Declaration of Conformity: L Panasonic System Networks Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/ EC. - Page 8 Contact to Authorised Representative: Panasonic Testing Centre Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, Germany Information for Users on Collection and Disposal of Old Equipment and used Batteries These symbols (1, 2, 3) on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste.
- Page 9 8. The guarantee period applicable to this product shall be 12 months. Please keep these operating instructions with your receipt. Panasonic Business Systems U.K. Receipt No. Date of purchase Model No.
- Page 10 This material is copyrighted by Panasonic System Networks Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic System Networks Co., Ltd. © Panasonic System Networks Co., Ltd. 2010...
