Thank you for purchasing this Panasonic product. Please read this manual carefully before
using this product and save this manual for future use.
Please use the batteries provided and charge the batteries for about 6 hours (KX-TPA70)/3
hours (KX-TPA73) before using the handset for the first time. For details, see 9.2.3 Charging
the Batteries, page 114 in this manual.
Note
• In this manual, the suffix of each model number is omitted unless necessary.
• The illustrations such as some keys may differ from the appearance of the actual product.
• Certain products and features described in this document may not be available in your
country or area. Contact your phone system dealer/service provider.
• The contents and design of the software are subject to change without notice.
Document Version: 2020-07
KX-TGP700
Operating Instructions
Base Unit for SIP Cordless Phone
Model No.
KX-TPA70/KX-TPA73
Model No.
KX-TPA70/KX-TPA73
KX-TGP700
SIP Cordless Handset
