AUDI A4 A5 Q5 User's manual

1. It is suitable for all AUDI NON MMI system A4/Q5/A5 from 2005 up version.

2. Built‐in CANBUS with car original button switch

3. Built‐in FM transmittion. When setting Radio channel into FM87.9, exteral audio will be sound from car

original speaker.

4. With OEM cable harness, 100% plug and play, which can avoid damaging the original system.

5. With two AV, RGBS input, as well as two AV, LVDS output Synsh

6. Built‐in GPS function (optional, when place).

7. Auto switch rear camera when gear in reverse backwords.

GPS Technical Dat:

1. Main Control Processor: SiRF Atlas IV, and main frequency: 500MHZ

2. main storage: 64M ,128M (optional:DDR I)

3. Flash storage: 64M,128M,1G,2G (optional:Nand flash )

4. video output format: RGB，CVBS，YC，digital: RGB565

composite sync signal, and synchronizing signal separation

5. Synch signal:

6. video output system: NTSC，PAL

7. video output resolution: 320X240,400X234,480X234,800×480

8. GPS antenna power: 3-5V

9. Operation system: WINCE.NET 6.0 Core Version

10. Input voltage: 5V-24V

11. Touching panel connection: 4PINS resistance touching function

12. Memory Card: SD/MMC/SDHC（SDHC）4GB~32GB

Page 1 AUDI A4 A5 Q5 User’s manual 1. It is suitable for all AUDI NON MMI system A4/Q5/A5 from 2005 up version. 2. Built‐in CANBUS with car original button switch 3. Built‐in FM transmittion. When setting Radio channel into FM87.9, exteral audio will be sound from car original speaker. 4. With OEM cable harness, 100% plug and play, which can avoid damaging the original system. 5. With two AV, RGBS input, as well as two AV, LVDS output Synsh 6. Built‐in GPS function (optional, when place). 7. Auto switch rear camera when gear in reverse backwords. GPS Technical Dat: 1. Main Control Processor: SiRF Atlas IV, and main frequency: 500MHZ 2.
Page 2 Installation video interface: OEM Cable connection: ...
Page 3 The OEM cable harness: Green cable Is for reverse light +12V 14PINS LVDS cable Instruction picture 14PINS LVDS cable to Video unit: LVDS out...
Page 4 After you detached the front panel, you can also instal our filexible touch panel also in front the Original monitor. And after finish the all installation, you can activate the GPS function first, when Turn on power, can use igo8, Garmin NAVI MAP system. DIP SET Instruction...
Page 5: Switch Operation
Three button of video Intehration is for adjusting Picture’s: Brightness, Saturate, Contrast. Picture position: H, L Switch operation: The parts with the Video Integration: RGB, AV, Speaker, FM connector GPS Antenna Oem cable harness for plug and pla ...
