GE Monogram ZGU48L4GHSS Datasheet

ZGU48N4GHSS
(Natural Gas)
ZGU48L4GHSS
(Liquid Propane)
Dimensions and Specifications (in inches)
Professional cooktops offer a number of choices in size and
cooktop configurations.
ZGU48N4GHSS
with 4 burners, grill and griddle (Order ZGU48L4GHSS for LP gas)
Product Dimensions and Clearance
A 48"- or 54"-wide professional vent hood with a minimum 1200 CFM
is recommended for installation over this cooktop.
• Install the hood 30" to 36" above the cooking surface
47-7/8"
Allow Clearance
Below the Burner Box
for the Regulator and
Gas Connections
Specification Revised 10/05
130450
– GE Monogram 48" Professional Gas Cooktop with
4 Burners, Grill and Griddle
Clearances between cooktop and side
wall or combustible material must be
at least 12" on each side.
26-5/8"
8-7/16"
22-3/4"
7/8"
46-1/8"
Install Options
• The cooktop stainless steel surface will be 1/2" higher than
adjacent countertops.
• In 24"-deep cabinets, the front of the cooktop will be
approximately 1-7/8" beyond the front of the countertop.
22"
22"
High
High
Back
Back
12"
12"
Countertop
Countertop
Level
Level
8-7/16"
8-7/16" 1/2"
1/2"
Allow Additional Clearance
Allow Additional Clearance
Below the Burner Box for
Below the Burner Box for
Gas Connections
Gas Connections
4" to Center Line
4" to Center Line
of Gas Inlet
of Gas Inlet
on the Left
on the Left
1/2"
1/2"
Cabinet Face - Projecting Control Panel
Cabinet Face - Projecting Control Panel
Cabinet Face - Flush Control Panel
Cabinet Face - Flush Control Panel
Cooktop
Cooktop
Front Projects Outward as Shown
Front Projects Outward as Shown
From Standard Depth Cabinets.
From Standard Depth Cabinets.
Cooktop
Cooktop
2-1/2"
NOTE: These cooktops require 8" free space below the countertop Front Flush With Cabinets - a Minimum
8"
Front Flush With Cabinets - a Minimum
of 25-3/4" Cabinet Depth Required
of 25-3/4" Cabinet Depth Required
to house the cooktop burner box. Allow additional clearances below
the burner box to install the regulator and make house gas supply
connections. Use a 90° elbow to route the gas connections and limit
interference with drawers or other cabinetry features.
For answers to your Monogram,
GE appliance questions, visit our website at
®
GEAppliances.com or call GE Answer Center
service, 800.626.2000.
22" High
22"
26-5/8"
Backsplash
26-5/8"
High
with Shelf
Back
22" High
12" High
22" High
12"
Backsplash
Backsplash
Backsplash
Countertop
with Shelf
with Shelf
Level
12" High
12" High
8-7/16"
Backsplash
1/2"
Backsplash
Allow Additional Clearance
Below the Burner Box for
Gas Connections
4" to Center Line
of Gas Inlet
22-3/4"
on the Left
1/2"
23-1/4"
22-3/4"
22-3/4" Cabinet Face - Projecting Control Panel
23-1/4"
Cabinet Face - Flush Control Panel
23-1/4"
2-1/2"
2-1/2"
Cooktop
1/2" Above Adjacent
1/2" Above Adjacent
Countertops.
Countertops.
Front Projects Outward as Shown
From Standard Depth Cabinets.
Cooktop
1/2" Above Adjacent
1/2" Above Adjacent
Countertops.
Countertops.
Flush With Cabinet Front
Front Flush With Cabinets - a Minimum
Flush With Cabinet Front
of 25-3/4" Cabinet Depth Required
Flush With Cabinet Front
GE Profile or
® ™
®
26-5/8"
2-1/2"
1/2" Above Adjacent
Countertops.
1/2" Above Adjacent
Countertops.
