USER'S MANUAL AND OPERATING INSTRUCTIONS
DURAHEAT
MODELS:
GENERAL HAZARD WARNING
Failure to comply with the precautions and instructions provided with
this heater, can result in death, serious bodily injury and property loss,
or damage From the hazards oF Fire, explosion, burn. asphyxiation, carbon
monoxide poisoning, and/or electrical shock.
only persons who can understand and Follow the instructions should
use or service this heater.
iF you need assistance or heater inFormation such as an instruction
manual, labels, etcetera, contact the manuFacturer.
retain this instruction manual For Future reFerence.
GFA40
GFA50A
GFA60A
GFA100A
GFA125A
GFA150A
CSA 2.14a-2007, ANSI Z83.7a-2007
World Marketing of America, Inc.
PO Box 192, 12256 William Penn Hwy.
Mill Creek PA 17060-0192
www.worldmkting.com
PROPANE
CONSTRUCTION HEATER
(40,000 BTU/HR,
(30,000/50,000 BTU/HR,
(30,000/60,000 BTU/HR,
(70,000/100,000 BTU/HR, FORCED - AIR)
(70,000/125,000 BTU/HR, FORCED - AIR)
(120,000/150,000 BTU/HR, FORCED - AIR)
C
US
(Tel) 1-800-776-9425
Printed in China
FORCED - AIR)
FORCED - AIR)
FORCED - AIR)
Rev. 1/10
