- Page 1 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Instant Hot Water Dispenser Owner’s Manual Installation, Care & Use Instalacion, Cuidado & Uso Installation, Sion & Utilisation In-Sink-Erator www.NeedPlumbingSupplies.com 800-728-8890...
- Page 2 We are delighted that you have chosen the InSinkErator ® Instant Hot Water Dispenser to be a part of your home. This unique appliance will save you time and effort in the kitchen, and you’ll enjoy discovering new uses for it each day. That’s exactly why millions of people are now using an InSinkErator Instant Hot Water Dispenser.
- Page 3 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Identify the model of your instant hot water dispenser and record it here:________________ HC1100 GN1100 HC-View H-View HC-Wave H-Wave H990 H770 HOW TO USE THIS INSTRUCTION MANUAL These instructions are separated into main sections, indicated by numbers, and subsections, indicated by capital letters.
- Page 4 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 COMPONENTS IN THIS PACKAGE Semi-circular HC1100 GN1100 Rubber O-Ring Hex Nut Hex Tool Mounting Plate Filter 3/8" Tubes (2) Discharge Tube 3/4" Screws (4) Plug (1) Brass Nut / Ferrule / Tube Insert Snap-Connect SST-FLTR Fitting (3 pieces) Quick Connector Filter Head...
- Page 5 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 IF INSTALLING ONLY NEW FAUCET At tank top, depress release ring into quick-connect fitting securing blue 1/4" Release Ring tube and gently pull line out of fitting. Blue Tube Pull white 7/16" tube and clear 5/16" 1/4"...
- Page 6 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 START HERE PROPER INSTALLATION SHOULD TAKE ABOUT 2-4 HOURS PREPARATION Required minimum from Maximum counter Identify locations for the dispenser center of hole to wall thickness (depth) faucet, tank and filter (if applicable). HC1100 .... 4" ......3" Check to make sure there is proper GN1100 ....
- Page 7 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 INSTALLING THE FAUCET - SERIES 1100 HC1100 / GN1100 Unpack dispenser components. On a firm, flat surface, carefully straighten the copper tubing. Property Damage: Do not pinch or break copper tubing. Do not distort the last 1 inch of tubing. HC1100 / GN1100 Ensure that the black O-ring is properly seated in the base of the...
- Page 8 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 INSTALLING THE FAUCET - HC/GN HC /GN Unpack dispenser components. On a firm, flat surface, carefully straighten the copper tubing. Remove the wing nut from the valve body. Property Damage: Do not pinch or break copper tubing.
- Page 9 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 INSTALLING THE FAUCET - VIEW/ WAVE View /Wave Unpack dispenser components. On a firm, flat surface, carefully Plug straighten the copper tubing. Remove the wing nut from the valve body. Property Damage: Do not pinch or break copper tubing.
- Page 10 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 INSTALLING THE FAUCET - H990 H990 Unpack dispenser components. On a firm, flat surface, carefully straighten the copper tubing. Brass Property Damage: Do not pinch or break copper tubing. Do not distort the last 1 inch of tubing. H990 Ensure that the black rubber gasket is properly seated into the base of...
- Page 11 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 INSTALLING THE FAUCET - H770 H770 Unpack dispenser components. On a firm, flat surface, carefully straighten the copper tubing. Property Damage: Do not pinch or break copper tubing. Do not distort the last 1 inch of tubing. H770 Ensure that the fiber gasket is properly seated against the base of...
- Page 12 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 MOUNTING THE TANK Select a spot under the sink to mount tank vertically within reach of both Tank must be plumbing and electrical connections. mounted level The tank should be within 16" or less to ensure of faucet water lines and within 30"...
- Page 13 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Filtration standard with HC1100 & GN1100 INSTALLING FILTRATION Available as an option for all other models Mark hole locations for filter head and bracket in a spot that allows for filter replacement. Drill 1/8" starter holes and attach bracket to wall with wood screws, turning until snug.
- Page 14 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 FINAL WATER CONNECTION HC1100 / GN1100 / HC / HC-Wave / HC-View Brass Nut Brass Nut At the end of the white 3/8" tube from the Ferrule s Insert Brass Nut Ferrule filter or quick-connector, slide the supplied Ferrule Brass Insert brass nut and ferrule over the tube and...
- Page 15 Periodically inspect the unit for any signs of leakage and immediately remove from service any unit suspected of leaking. An instant hot water dispenser, like any water heater, has a limited life and will eventually fail. To avoid possible property damage, this instant hot water dispenser should be regularly examined for leakage and replaced when necessary.
- Page 16 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 CARE AND USE Electric Shock Hazard: To prevent electrical shock, disconnect power before servicing unit. Use only a properly grounded and polarized electric outlet. ADJUSTING THE THERMOSTAT FILTER GUIDE AND REPLACEMENT approx. 200° Factory temperature pre-set is 200˚F. Replace filter cartridge when there is an obvious To reset the thermostat to 200°, decrease in water flow to the faucet or if there is an...
- Page 17 In-Sink-Erator Internet Dealer Please read Troubleshooting Guide and/or visit www.NeedPlumbingSupplies.com 800-728-8890 www.insinkerator.com before calling AnswerLine ™ TROUBLESHOOTING PROBLEM POSSIBLE CAUSE WHAT TO DO Water and steam spits • Unit is boiling. • Depress faucet lever to release some water from forcefully from spout the tank.
- Page 18 In-Sink-Erator Internet Dealer www.NeedPlumbingSupplies.com 800-728-8890 Instant WaterDispensers. The Next Necessity. InSinkErator Division Emerson Electric Co. 4700 21st Street Racine, WI 53406-5093 www.insinkerator.com 43666 0706 In-Sink-Erator www.NeedPlumbingSupplies.com 800-728-8890...
