Quatech ABDG-BR-DP501 Specfications

Airborne Enterprise Class Wireless Ethernet Solutions
Ethernet to 802.11b/g Wireless LAN
ABDG-BR-DP501 Ethernet Bridge and ABDG-ET-DP501 Ethernet Adapter
Airborne TM is a line of highly integrated
802.11 radios and device servers,
designed to address the demands of
complex machine-to-machine (M2M)
applications. Utilizing the latest 802.11
microprocessor and network
technologies, the Airborne family of
products provide a broad encompassing
solution for wireless applications
requiring performance, reliability and
advanced
security.
The Airborne Ethernet bridge family
allows an Ethernet enabled device to
connect to a high performance wireless
802.11 network. The integrated Network
Address Translation (NAT) functionality
provides plug and play connectivity and
simple integration to any system with an
Ethernet port. The Ethernet interface
supports auto rate detection up to
100Mb/s. The ABDG-ET-DP501 includes
a full featured 802.11b/g radio and a high
performance ARM9 MCU running
embedded Linux.
Enterprise Class Security
WPA2-Enterprise is the leading wireless
security standard for enterprise networks
and is fully supported by the Airborne
Enterprise products.
The integrated supplicant supports a
wide range of EAP processes including:
EAP-TLS/MSCHAPv2
EAP-TLS/MD5
EAP-TTLS/MSCHAPv2
PEAPv0/MSCHAPv2
LEAP
Airborne supports the most flexible
certificate delivery and management
available in the wireless device market,
along with WEP, WPA, WPA2, 802.11i
and Pre-shared Key (PSK), no other
wireless solution provides a more
comprehensive security solution.
Reliability
Designed by Quatech specifically to
meet the demands of the industrial,
automotive and medical markets, the
Airborne Ethernet Bridge has the widest
operating temperature range and highest
level of reliability available, all backed by
a five year limited warranty. Quatech also
provides FCC Modular certification,
minimizing requirements for further
regulatory testing by original equipment
manufacturers.
Applications
Previous generations of Airborne
Wireless Ethernet Bridge have been
integrated and deployed into a wide
range of applications across various
industries including:
Medical equipment
Vehicle telematics & diagnostics
Material handling & logistics
Industrial Automation
Test & measurement
Security & access control
Model Selection Guide
Interface
Model No.
10 Base-T 10/100
ABDG-BR-DP501
ABDG-ET-DP501
ABDG-ET-DP101
707 Dayton Road | P.O. Box 1040 | Ottawa, IL 61350
+1 815.433.5100 | www.bb-elec.com
KEY FEATURES
Extended operating temperatures
(-20° to +85°C) and environmental
specifications
Plug-n-Play Ethernet to 802.11
Connectivity
Enterprise Class wireless security
(WPA2-Enterprise, WPA2-PSK, WPA-
PSK, WEP, EAP) with Certificates
Plug-and-Play LAN and Internet
Connectivity
Compact Package Outline
Integrated External Antenna
Integrated Ethernet Cable and RJ-45
(Male) Connector
Software-configurable 802.11b/g
Interface
Advanced utilities for discovery,
configuration and management of
Airborne Ethernet device
Worldwide Certificate Support- FCC Part
15 Class B Sub C Modular Approval,
IOC, CE, ETSI, ROHS, WEEE
5 year warranty
Quatech's Airborne Enterprise Wireless
Ethernet Bridge extends the reputation of
the family further by drawing on
experience of Quatech application
engineers across hundreds of wireless
M2M deployments.
The advanced technologies implemented
in the Quatech Enterprise 802.11
Ethernet Bridge provide an industry-
leading solution with breakthrough
performance and security for M2M
applications and drop in replacements for
existing 802.11b and 802.11b/g
networking modules.
WiFi
NAT WEP
Ethernet 802.11b/g
64 & 128 bit)
2.5
3
2.5
Security
WPA WPA2 LEAP EAP
