Airborne Heavy Duty 802.11b/g Wireless Ethernet Bridge
ABDG-ET-HD101 series
Heavy duty enclosure for extreme
conditions
Create a wireless connection between
802.11 wireless LAN device with an
Ethernet port to transparently convey data
between the device and a 10Base-T
interface. The heavy duty ethernet bridge
includes
802.11b/g
technology
enables systems and opens up the world
of
remote
device
monitoring
management.
With a durable enclosure, it shields the
device from external elements, including
water, dust and other environmental
threats.
This powerful tool is an ideal
solution for vehicle mounting, industrial
shop floors or any other extreme
environment surroundings.
802.11 wireless connectivity
The Airborne Heavy Duty Wireless
Ethernet Bridge is an ethernet to 802.11
bridge capable of linking a host system to
a wireless 802.11 network.
The highly integrated hardware enables
plug-and-play
capabilities,
significantly reducing complexities of
wireless system deployment and network
connectivity.
The device includes a physical interface
to the wired network through a 12-pin
connector integrated into the enclosure.
The 802.11 RF interface is provided by an
enclosure mounted RP-SMA connector.
The device is supplied in a Deutsch EEC-
325X4B enclosure and is available in both
sealed
and
*unsealed
Connection to the Ethernet power and
control interfaces is through the 12-pin
DTM13-12PA-R008 receptacle.
Applications
The Airborne bridge enable telematics
systems to connect to corporate and
public wireless LAN networks, commonly
deployed at warehouses, ports and transit
centers.
that
Ruggedized hardware is incorporated for
harsh environmental conditions faced by
and
trucks, buses, heavy equipment and
automobiles.
In addition, the Airborne
Heavy Duty Bridge runs directly on
vehicle battery power to enable easy
integration
by
providers.
* For sealed versions, please contact Airborne Sales Team
Model Selection Guide
802.11b
Model No.
ABDG-ET-HD101
To evaluate all available features and receive evaluation tools, order below.
ABEG-ET-HD101
Accessory Kit, 802.11b/g Ethernet bridge
while
versions.
telematics
solution
WiFi
Interface
802.11b/g
10 Base T
(64 & 128 bit)
707 Dayton Road | P.O. Box 1040 | Ottawa, IL 61350
+1 815.433.5100 | www.bb-elec.com
KEY FEATURES
Extended operating temperature range
(-20°C to +85°C) and environmental
specifications
Advanced security support includes
WEP 64/128, WPA (TKIP), 802.1x
(LEAP)
SAE J1455 compatible power supply
Low power modes
Ruggedized Deutsch enclosure and
connector
10Base-T interface
802.11b/g compliant radio
Quick time to market & reduced
development costs
FCC Part 15 Class B Sub C Approval
Reduces need for RF and
communications expertise
RP-SMA connector available for cable
or direct antenna connection
Device integration does not require OS
specific drivers
Security
RoHS
WEP
Compliant
WPA
LEAP
