AirborneDirect
Serial Bridge
Quick Start Guide
Package Contents
™
The AirborneDirect
Serial Bridge includes the following items:
™
One AirborneDirect
Serial Bridge
One AC power adapter and cord (except ABSE-100D-POC model)
A mounting cradle (mounting hardware is user-supplied)
A female-to-female null-modem adapter
A female RS-232 loopback adapter
An AirborneDirect Serial Bridge Quick Start Guide (this document)
One CD containing documentation and software.
Access Point
100-8000-131G
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Quatech AirborneDirect
Summary of Contents for Quatech AirborneDirect
-
Page 1: Quick Start Guide
One AC power adapter and cord (except ABSE-100D-POC model) A mounting cradle (mounting hardware is user-supplied) A female-to-female null-modem adapter A female RS-232 loopback adapter An AirborneDirect Serial Bridge Quick Start Guide (this document) One CD containing documentation and software. Access Point 100-8000-131G... -
Page 2: Getting Started Quickly
Getting Started Quickly The AirborneDirect Serial Bridge is shipped ready-to-use. Follow these quick steps to set up the Serial Bridge Unpack the Evaluation Kit Unpack the AirborneDirect Serial Bridge and compare the package contents with the items listed on the front of this Quick Start Guide. If any item is missing or damaged, contact Quatech immediately. - Page 3 (the Wireless Device Server will try to associate with the first, available “best-quality” AP). Either remove power from the other APs or perform the setup in a remote location. Connect Your AirborneDirect™ Serial Bridge Plug the DB-9 RS-232 connector on the other end of the cable into the RS-232 serial port on the computer or other serial client.
- Page 4 If the LEDs indicate a problem with a wired or wireless connection, remove the power source from the Serial Bridge, wait a few seconds, and re-apply power. If the LEDs still do not behave ™ appropriately, refer to the AirborneDirect Serial Bridge Users Guide (on the CD) for troubleshooting suggestions.
- Page 5 Record Settings from Your Access Point’s Configuration Program On the LAN host, use your Web browser to log into your Access Point’s online configuration program at the appropriate IP address (for example: http://192.168.0.1). Your Access Point documentation provides this procedure. Go to the appropriate screen in that program and perform these steps: Find the Service Set Identifier String (SSID) Go to the Wireless Settings or equivalent screen in your Access Point’s configuration application that shows the Access Point’s SSID.
- Page 6 Configure the Serial Bridge using the Airborne Configuration Center On the LAN host, launch the Airborne Configuration Center (ACC). An icon to launch the ACC will be found in your Windows Start menu if you properly installed the software as directed in Step 3. The ACC’s initial window displays a list of devices detected on your local network.
-
Page 7: Where To Go From Here
For more information, see the AirborneDirect Serial Bridge User’s Guide. ™ Quatech also offers developer documentation for OEMs and developers interested in using Airborne wireless technologies with their own products and applications. For more information, please contact Quatech. 5675 Hudson Industrial Parkway Hudson, OH 44236 Tel: 330.655.9000...
