Monogram. ™
ZGU36N6DSS—36" Professional Gas Cooktop
Dimensions and Specifications (in inches)
35-7/8"
34-7/8"
Adjacent Cabinet
and Countertop
Counter Sunk
Screws
Specification Created 7/01
26-5/8"
8-7/16"
22-3/4"
1/2"
2-1/2"
8"
2"
17"
Locate gas inlet on
back wall or on floor
2" from back wall
Cutting the Countertop Opening:
Measure carefully when cutting the countertop.
Make sure sides of the opening are parallel.
• This Monogram
fit in 36" or larger base cabinet.
• This cooktop requires 8" free space below
the countertop.
• The cooktop is designed to hang from the
countertop from its side flanges.
• Smooth any rough edges on the countertop
before installing cooktop.
–Formica countertop edges must be finished.
The countertop must be strong enough to support
the weight of the cooktop.
• Support cleats can be secured to cabinet
sides OR build a support deck or box inside
the cabinet which will support the weight
of the cooktop.
–Build the support box using a solid material,
cut a 5" x 5" square in the left rear corner for
the gas inlet and power cord clearances.
Installation Information:
Before installing, consult installation instructions
(Pub. No. 49-8812) packed with product for current
dimensional data.
16"
For answers to your Monogram,
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center
R
™ gas cooktop is designed to
GE Profile
®
® service, 800.626.2000.
Listed by
Underwriters
Laboratories
or
™
