GE Monogram ZGU384LSMSS Dimensions And Installation Information

ZGU384LSMSS/ZGU384NSMSS
GE Monogram
Dimensions and Installation Information (in inches)
3-3/4"
19-5/8"
2-7/8" Min.
from Cutout
to Rear Vertical
Combustibles
2-1/2" Min.
from Cutout
to Front of
Countertop
Note: The cooktop cutout is rectangular.
The bowed front edge of the cooktop will sit on top
of the counter.
These cooktops may be installed in combination with a
Monogram downdraft vent, a Monogram single oven or a
Monogram warming drawer. See installation instructions
for details.
Model ZGU384NSMSS - Natural Gas
Model ZGU384LSMSS - Liquid Propane
These stainless steel cooktops are factory set for natural or
liquid propane gas. Be sure to order the correct model for
the installation situation.
For answers to your Monogram,
GE appliance questions, visit our website at
®
ge.com or call GE Answer Center
800.626.2000.
30" Stainless Steel Gas Cooktop
®
21-5/8"
Deep at Center
30-3/4"
28-1/2"
30" Min.
Cabinet Base
GE Profile or
® ™
service,
®
12" Min.
from Cutout
to Side Walls
Note: Reference Instructions, GE Monogram 30"
Stainless Steel Cooktop Installation, packed with
product, for complete details.
The house gas supply should be at least 1" from
the back wall.
The electrical outlet should be 12" below the
countertop and within reach of the 4 ft. power cord.
Specification Revised 6/07
Listed by
Underwriters
Laboratories
130241
