Summary of Contents for Chauvet Radius
- Page 1 User Manual...
-
Page 2: Table Of Contents
5. Technical Information ..............13 Product Maintenance .................. 13 General Troubleshooting ................14 Contact Procedure ..................15 CHAUVET® Contact Information ..............15 Returning Products to CHAUVET® .............. 15 6. Technical Specifications ..............16 Page 2 of 16 Radius™ 2.0 User Manual Rev. 2... -
Page 3: Before You Begin
CHAUVET®. Failure to do so in a timely manner may invalidate your claim with the carrier. In addition, keep the container and all the packing material for inspection. -
Page 4: Product At A Glance
Please contact the nearest authorized technical assistance center. · Keep this User Manual for future consultation. If you sell the product to another user, be sure that they also receive this document. Page 4 of 16 Radius™ 2.0 User Manual Rev. 2... -
Page 5: Introduction
2. I NTRODUCTION Product Overview Back Panel Fuse Holder Sound Sensitivity Knob LED Display Radius™ 2.0 User Manual Rev. 2 Page 5 of 16... -
Page 6: Product Dimensions
Product Dimensions Page 6 of 16 Radius™ 2.0 User Manual Rev. 2... -
Page 7: Setup
3. S ETUP AC Power The Radius™ 2.0 has an auto-ranging power supply and it can work with an input voltage range of 100~240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 8: Power Linking
Power Linking Diagram Other products You can power link up to twenty (20) Radius™ 2.0 units on 120 VAC or up to thirty-seven (37) Radius™ 2.0 units on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET®... -
Page 9: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes section. Orientation The Radius™ 2.0 may be mounted in any position; however, make sure adequate ventilation is provided around the product. · Rigging Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes. -
Page 10: Operation
White rotation Auto Programs Amber rotation All color rotation All color rotation and strobe Color cycle rotation Auto Program S__1-S100 Sets auto program speed Speed Sound-Active Sets Sound-Active Mode Mode Page 10 of 16 Radius™ 2.0 User Manual Rev. 2... -
Page 11: Configuration (Dmx)
The Radius™ 2.0 has a single 3-channel personality. Personalities The Radius™ 2.0 uses up to 3 DMX channels in its highest DMX mode, which defines the highest configurable address to 510. and Starting When selecting a starting DMX address, always consider the number of DMX channels Address the selected DMX mode uses. -
Page 12: Configuration (Standalone)
Master/Slave The Master/Slave mode allows a single Radius™ 2.0 unit (the “master”) to control the actions of one or more Radius™ 2.0 units (the “slaves”) without the need of a DMX Mode controller. The master unit will be set to operate in either Automatic or Sound-Active mode, while the slave units will be set to operate in Slave Mode. -
Page 13: Technical Information
Wipe any dirt or grime to the outside edges of the transparent surfaces. · Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Radius™ 2.0 User Manual Rev. 2 Page 13 of 16... -
Page 14: General Troubleshooting
#32 Terminator not connected Install a terminator, as indicated in the DMX Primer section. If you still experience problems after trying the solutions provided, contact CHAUVET® Technical Support. Page 14 of 16 Radius™ 2.0 User Manual Rev. 2... -
Page 15: Contact Procedure
If you live in the UK or Ireland, contact CHAUVET® Europe Ltd.(see below). · If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your distributor of record. Refer to our Web site for contact details of distributors outside the US, United Kingdom, or Ireland. -
Page 16: Technical Specifications
Maximum External Temp. Cooling System 104° F (40° C) Convection I/O Connectors Connector Type Channel Range 3-pin XLR Sockets Ordering Product Name Item Code Item Number Radius™ 2.0 03050524 RADIUS20 Page 16 of 16 Radius™ 2.0 User Manual Rev. 2...
