- Page 1 P-3202H-Bb G-PON VoIP IAD Firmware v1.0 Edition 1, 09/2009 DEFAULT LOGIN DETAILS IP Address: http://192.168.1.1 User Name admin Password: 1234 Copyright 2009...
- Page 2 Device Panels POWER PHONE ETHERNET ON/OFF POWER PHONE ETHERNET RESET PORT PORT...
- Page 3 ENGLISH Overview This device is an Integrated Access Device (IAD) which combines high- speed fiber optic (G-PON) Internet access, a built-in switch, and Voice over IP (VoIP) technology to allow you to use an analog telephone to make phone calls over the Internet. In This Guide, You Will: •...
-
Page 4: Hardware Connections
Hardware Connections 1. PON: Connect the fiber optic cable from your ISP to this port. 2. ETHERNET: Use an Ethernet cable to connect a computer to one of these ports for initial configuration and/or Internet access. 3. PHONE: Use a telephone cable (and any telephone adapter provided with your device) to connect your telephone to the PHONE 1 port. -
Page 5: The Web Configurator
ENGLISH Look at the LEDs (lights) on the top panel of the device. • The POWER light blinks during start-up and is green once the device is ready. If it turns red, then that means there has been a failure during the start up routine. •... - Page 6 2. Enter the user name admin (default) and Password, then click the Login button. If the login screen does not display, make sure you allow web browser pop-up windows, JavaScript and Java permissions. Your computer should be also set to get an IP address automatically from a DHCP server.
- Page 7 ENGLISH 2. When the Status screen displays, expand the Network menu in the navigation pane and then click WAN. 3. When the Internet Access Setup screen displays, select an Encapsulation method. If you choose PPPoE encapsulation, then you must enter a User Name and Password.
- Page 8 If you choose IP encapsulation, then you must enter a method for obtaining an IP address on your device. Choose Obtain an IP address automatically if your ISP dynamically assigns IP addresses with a DHCP server. Otherwise, choose Static IP Address and enter the information as provided by your ISP.
- Page 9 ENGLISH VoIP Setup This section shows you how to configure your Voice over IP (VoIP) settings so that you can place calls over the Internet. When you make Internet phone calls, your device utilizes a protocol known as ‘SIP’. Be sure to use any connection settings that may have been provided by your VoIP service provider.
- Page 10 4. Select Active, then enter the following information as it was provided by your VoIP service provider: • SIP Local Port - This is the “listening” port to which incoming call requests are received. • SIP Server Address - This is the IP address or domain name of the SIP server.
- Page 11 ENGLISH 5. On the SIP Account screen, select a SIP Account. It does not matter which one if this is your first time configuring this. 6. Select Active SIP Account, then enter the following information (if it was provided by your VoIP service provider): •...
-
Page 12: Make Phone Calls
Make Phone Calls Follow these directions to make calls over the Internet. • To dial a SIP number that only uses numbers (for example, “12345”), dial the number on your phone’s keypad. You can also set up a speed-dial entry, if you want. See the User’s Guide for instructions.
