- Page 1 “When You Need More Than Staples.” Toll Free: 800-658-8788 Fax: 801-927-3037 info@abcoffice.com IDEAL CUTTERS Model 4850 (18-3/4”) Model 4850-90 (18-3/4”) Model 5250 (20-1/2”) Model 6550 (25-1/2”) Model 6550-90 (25-1/2”)
-
Page 2: Safety Rules
Safety Rules Ensure that at no time more than one person is working at the machine. Leave the key for the safety lock with the person responsible for the cutting machine. Power operated cutting machines must be operated only by trained and reliable personnel. Part of the training is to become familiar with the operating instructions. -
Page 3: Features And Operation
Insert the four securing bolts for the stand into provided holes and secure with nuts. Place paper tray (#10) into the stand (#8). For models IDEAL 4850, IDEAL 4850-90, and IDEAL 5250, connect power cord with plug to a normal single phase AC socket. - Page 4 Re-set button (#14) Before the knife can be activated on models IDEAL 4850, IDEAL 5250 and IDEAL 6550, the re- set button has to be pressed to re -establish the “ready to cut” status of the machine. The yellow pilot light in the viewing window (#10) illuminates and indicates that the machine is ready to cut.
- Page 5 Under the viewing window (#16) the measuring scale rotates in accordance with the back gauge movement. The exact measurement is to be read beneath the indicator. To avoid inaccuracies, the scale has to be read vertically from above. Optical cutting indicator With exception of the IDEAL 5250, all other IDEAL power operated paper cutters with automatic clamp are equipped with an optical cutting indicator.
-
Page 6: Maintenance
The following steps apply to models IDEAL 4850-90 and IDEAL 6550-90. Please note that with the models IDEAL 4850, IDEAL 5250 and IDEAL 6550, the re-set button (#14) must always be pushed prior to activating the knife with the two push buttons. - Page 7 IMPORTANT – Hook cutting stick into pin, which is located on the left between the knife guide plates. IDEAL 4850-90 (5250): Insert knife holders into second and fourth threaded hole (B and D) of the sharp knife. IDEAL 6550-90: Insert knife holders into the first and fourth threaded holes from the left (A and D) of the new knife.
-
Page 8: Troubleshooting
IMPORTANT – If the knife has been lowered by means of the cutting depth adjustment screw (#6) to compensate for a worn cutting stick , then this adjustment screw (#6) has to be turned back to its highest setting before the cutting stick (#5) is turned, rotated or exchanged. Then re-adjust screw (#6) again to obtain the optimal cutting depth. - Page 9 Should the machine cut out during operation, check the overload switches (#11 and #12). If one of the buttons of the overload switches has popped out, it can be re-set after a short period. Should the overload switch pop out again and cannot be re-set even after a few minutes, please contact your service technician.
