JUKI LU-2810-6 Specification

LU-2810-6
1-needle,Unison-feed,Lockstitch Machine
with Vertical-axis Large Hook with automatic thread trimmer of V-Belt type
LU-2860-6
2-needle,Unison-feed,Lockstitch Machine
with Vertical-axis Large Hook with automatic thread trimmer of V-Belt type
High and long arm has been adopted. Wide machine bed area contributes to improved workability.
The V-belt type machine head
the machine lineup following the Direct-Drive type.
LU-2810-6
Functions for improving seam quality and workability
Double tension provided as : standard
A dual-tension is provided as standard
responding to the sewing with thick thread
under a higher tension.
Multi-functional 6-string switch
(with automatic thread trimmer)
The machine with thread trimmer can
change over the needle thread tension
from single to double and vice versa
(increase the responsiveness to thicker
materials), change over the alternating
vertical movement amount, the stitch
length, etc. by simply pushing the
Multi-functional 6-string switch.
Wide machine bed area contributes to improved workability.
The machine is suited to sew car seats, sofas and bags, provided with
dramatically improved workability and functions required for sewing
large products and extra heavy-weight materials.
127
mm 103
347
mm
255
mm
The picture is LU-2860-6.
mm
is added to
LU-2860-6
New bobbin thread winder
New bobbin thread winder is no neccessity
of rolling thread manually.
Higher lift of the presser bar
A 20mm presser bar lift is achieved by
automatic presser bar lift, which provides
easy operation for joining leather and thick
sponges often applied to making luxurious
sofas.
Walking-foot/presser-foot alternating
vertical movement mechanism
The adopted feed mechanism makes up
less variance of the balance of the
alternating vertical movement amounts.
The maximum presser foot lift is 9mm
which can be adjusted with ease by the
large dial on top of the machine head.
Eccentricity of the feed
driving cam is adjustable.
Adjustment of the eccentricity of the feed
driving cam has been enabled. As a
result, the sewing machine is able to
perform sewing with the feed that is
best-suited to the material and thread
used. It is no longer necessary to prepare
other subclass model sewing machines.
20
mm
9
mm
