Page 2
1. Specifications ......................... 1 2. Threading the machine head ..................2 CAUTION This Instruction Manual for the LU-2828NV only describes their differences from the stan- dard models (LU-2828V). For safety-related information, carefully read and fully understand "Safety precautions" described in the Instruction Manual for the standard models before using your sewing ma-...
Page 3
Electronic control Alternate vertical feed control Electronic control Lubricating oil JUKI New Defrix Oil No. 1 (equivalent to ISO standard VG7) or JUKI MACHINE OIL No. 7 Number of patterns Sewing pattern ......99 patterns (For the polygonal shape sewing, as many as 10 patterns can be registered.)
Page 4
2. Threading the machine head WARNING : To protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. Thread the machine head following the order as illustrated in the figure.
