AX6240/AX6220
Energy-Efficient, DSP-Powered and Ethernet/USB-Controlled
2900/2000-Watt Low-Impedance amplifier
Architect's and Engineer's Specifications
Summary description: The amplifier shall be of Class H design with an energy-efficient switch-mode power supply and shall
provide two low-impedance output channels in a 2U rack-mountable fan-cooled chassis with integrated DSP and remote
Ethernet/USB control.
Digital signal processing (DSP) incorporated into the amplifier shall include delay, crossover, dynamics, parametric EQ
(8-band), and dynamic EQ (2-band). The amplifier's A/D and D/A converters shall be 24-bit/96 kHz.
Controls and indicators shall include the following:
• Master Encoder knob for setting volume and DSP parameters
• Indicator ring for power (yellow) and clipping (flashing red)
• LCD screen to display current DSP module and settings
• Up and Down buttons to select DSP modules and parameters
• Process button to select DSP processing modules
• Setup button to select DSP parameters
• Exit button to display the top-level DSP menu
• AC power switch on rear-panel to turn amplifier on/off
Connections to the amplifier shall include the following:
• Remote power on/off on 2-pin Euroblock socket
• Inputs A and B, balanced or unbalanced mic or line-level, on XLR/TRS combination jacks and on 3-pin Euroblock sockets
• Outputs on NL4 panel connectors (twist-lock) and on binding posts (bare wire or banana plugs)
• Ethernet on RJ45 jack for LAN connection
• USB jack for connecting a computer
• AC power on IEC connector
Cooling and protection shall include back-to-front ventilation provided by dual variable-speed fans. Each amplifier output
channel shall be protected against overload by a limiter. Each amplifier output channel shall incorporate independent DC
and thermal overload protection.
