► CPU Performance Tuning/Chipset Performance Tuning
Press <Enter> to go to its submenu.
CPU Permance Tuning
Advanced
Host Clock Override(1/100 MHZ)
CPU Voltage (1/10000 Volt)
IA Core Current Max(1/8 Amp)
Power Limit 1 Value (Watt)
Power Limit 2 Switch
Power Limit 2 Value
EIST
► Host Clock Override (1/100MHz)
This item is used to set the Host Clock Override. You can use [+] or [-] to adjust the value.
► CPU Voltage (1/10000 Volt)
This item is used to change the CPU voltage in a step of 0.004V. The voltage can be incre-
mented from 0.004V to 1.000V. You can use [+] or [-] to adjust the value.
► IA Core Current Max(1/8 Amp)
This item is used to set IA Core current max value for factory long duration power limit.
► Power Limit 1 Value (Watt)
This item is used to set the first power limit. You can use [+] or [-] to adjust the value. The set-
ting value: 0 - 500.
► Power Limit 2 Switch
This item is used to enabled/disabled the power limit 2.
► Power Limit 2 Value
This item is used to set the second power limit. You can use [+] or [-] to adjust the value. The
setting value: 0 - 500.
► EIST
You can enable/disable the EIST (Processor Power Management, PPM) through this item.
!
Enhanced Intel SpeedStep ® technology (EIST) allows the system to dynamically
adjust processor voltage and core frequency, which can result in decreased average
power consumption and decreased average heat production. There are some system
requirements must be met, including CPU, chipset, motherboard, BIOS and operation
system. Please refer to Intel website for more information.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
10000
0
780
35
[Enabled]
43
[Enabled]
