Statement:
This manual is the intellectual property of Foxconn, Inc. Although the
information in this manual may be changed or modified at any time,
Foxconn does not obligate itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
Version:
User's Manual V1.0 for A6VMX Series motherboard.
P/N: 3A220JS00-000-G
Symbol description:
Note: refers to important information that can help you to use motherboard
better.
Attention: indicates that it may damage hardware or cause data loss,
and tells you how to avoid such problems.
Warning: means that a potential risk of property damage or physical
injury exists.
More information:
If you want more information about our products, please visit Foxconn's
website: http://www.foxconnchannel.com
WEEE: The use of the symbol indicates that this product may not be
treated as household waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed informa-
tion about recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you pur-
chased the product.
Advertisement
Table of Contents
Related Manuals for Foxconn A6VMX Series
Summary of Contents for Foxconn A6VMX Series
- Page 1 This manual is the intellectual property of Foxconn, Inc. Although the information in this manual may be changed or modified at any time, Foxconn does not obligate itself to inform the user of these changes. Trademark: All trademarks are the property of their respective owners.
-
Page 2: Declaration Of Conformity
Declaration of conformity HON HAI PRECISION INDUSTRY COMPANY LTD 66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT, TAIPEI HSIEN, TAIWAN, R.O.C. declares that the product Motherboard A6VMX/A6VMX-S/A6VMX-K is in conformity with (reference to the specification under which conformity is declared in accordance with 89/336 EEC-EMC Directive) þ... - Page 3 Declaration of conformity Trade Name: FOXCONN Model Name: A6VMX/A6VMX-S/A6VMX-K Industry Inc. Responsible Party: Address: 458 E. Lambert Rd. Fullerton, CA 92835 Telephone: 714-738-8868 Facsimile: 714-738-8838 Equipment Classification: FCC Class B Subassembly Type of Product: Motherboard Manufacturer: HON HAI PRECISION INDUSTRY...
-
Page 4: Table Of Contents
Table of Contents Chapter Main Features Specifications.................... 2 Jumpers ....................18 Chapter BIOS Description Enter BIOS Setup ................. 21 Main menu .................... 21 1. Standard CMOS Features ............22 2. Central Control Unit ..............24 3. Advanced BIOS Features ............25 4. - Page 5 The pictures of objects used in this manual are just for your reference. Please refer to the physical motherboard. Attention: http://www. Please visit the Foxconn global English website ( foxconnchannel.com ) to download the latest BIOS file and drivers for this motherboard.
- Page 6 Chapter Thank you for buying Foxconn’s A6VMX Series motherboard. This series of motherboard is one of our new products, and offers superior performance, reliability and quality, at a reason- able price. This motherboard adopts the advanced AMD 690V+SB600 chipset, providing a computer platform with high integration, powerful compatibility and high performance-price ratio for users.
-
Page 7: Chapter Main Features Specifications
Chapter 1 Main Features Specifications - - English ·Micro ATX form factor : 244mm x 208mm Size · Socket AM2 for AMD Athlon 64 X2 ,Athlon X2 ,Athlon 64 and Sempron processors · Socket AM2+ for AMD Phenom processor ·Supports HyperTransport Technology ·Northbridge: AMD 690V Chipset... - Page 8 Chapter 1 Main Features ·2 x USB 2.0 headers (supports 4 USB 2.0 ports) Internal I/O ·4 x SATA connectors Connectors ·1 x Floppy connector ·1 x IDE connector ·1 x Chassis intruder header (INTR) ·1 x CD_IN header ·1 x S/PDIF_OUT header (optional) ·1 x TPM header (optional) ·1 x TV_OUT header ·1 x COM2 port header (optional)
-
Page 9: 产品规格
第一章 主要性能 产品规格- -简体中文 · mATX 结构: 244mm x 208mm 尺 寸 中 央 处 理 器 · 支持Socket AM2 规格 AMD Athlon 64 X2,Athlon X2,Athlon 64 和 Sempron 处理器 · 支持Socket AM2+ 规格 AMD Phenom 处理器 · 支持 HyperTransport 技术... - Page 10 第一章 主要性能 ·2 个 USB 2.0 接头（提供 4 USB 2.0 接口） 内 置 连 接 器 ·4 个 SATA 接头 ·1 个 软驱接口 ·1 个 IDE 接口 ·1 个 机箱开启侦测接头 ·1 个 CD_IN 接头 ·1 个 S/PDIF_OUT 接头（选配） ·1 个 TPM 接头（选配） ·1 个...
-
Page 11: Technische Daten
Kapitel 1 Hauptmerkmale Technische Daten--Deutsch ·Micro ATX-Formfaktor: 244 mm x 208 mm Größe · AM2-Sockel für AMD Athlon™ 64 X2, Athlon™X2, Athlon™ 64 und Sempron™-Prozessoren · AM2+-Sockel für AMD Phenom™-Prozessor ·Unterstützt HyperTransport™-Technologie Chipsatz ·Northbridge: AMD 690V ·Southbridge: AMD SB600 Speicher ·2 240-polige DIMM-Steckplätze ·... - Page 12 Kapitel 1 Hauptmerkmale Interne I/O- ·2 x USB 2.0-Anschlussleisten (Unterstützung für 4 USB Anschlüsse 2.0-Ports) ·4 x SATA-Anschlüsse ·1 x Diskettenlaufwerkanschluss ·1 x IDE-Anschluss ·1 x Gehäuse-offen-Anschluss (INTR) ·1 x CD_IN-Anschluss ·1 x S/PDIF_OUT-Anschluss(optional) ·1 x TPM-Anschluss(optional) ·1 x TV_OUT-Anschluss ·1 x COM2-Port-Anschluss(optional) ·1 x Front-Audio-Anschluss ·1 x ATX Power, 24-polig-Anschluss...
- Page 13 Capítulo 1 Principales funciones Características- -Español ·Micro ATX factor de forma: 244mm x 208mm Tamaño · Conector AM2 para procesadores AMD AthlonTM 64 X2, AthlonTM X2, AthlonTM 64 y SempronTM ·Conector AM2+ para procesador AMD PhenomTM ·Compatible con HyperTransportTM Conjunto de chips ·Northbridge: AMD 690V ·Southbridge: AMD SB 600 Memoria...
- Page 14 Capítulo 1 Principales funciones Conectores ·2 x Cabeceras USB 2.0 (admite 4 puertos USB 2.0) ·4 x Conectores SATA internos de E/S ·1 x Conector de disco flexible ·1 x Conector de IDE ·1 x Cabecera de intrusos en bastidor (INTR) ·1 x Cabecera de CD_IN ·1 x Cabecera S/PDIF_OUT(opcional) ·1 x Cabecera TPM (opcional)
- Page 15 Capítulo 1 Principais características Especificações- -Portugués ·Factor de forma Micro ATX de 244 x 208 mm Tamanho · Socket AM2 para processadores AMD AthlonTM 64 X2, AthlonTM X2, AthlonTM 64 e SempronTM · Socket AM2+ para processador AMD PhenomTM ·Suporta a tecnologia HyperTransportTM ·Northbridge: AMD 690V Chipset ·Southbridge: AMD SB 600...
- Page 16 Capítulo 1 Principais características Conectores ·2 x Conectores USB 2.0 (para 4 portas USB 2.0) ·4 x Conectores SATA internos de ·1 x Conector da unidade de disquetes entrada/saída ·1 x Conector IDE ·1 x Conector para detecção de intrusão no chassis(INTR) ·1 x Conector CD_IN ·1 x Conector S/PDIF_OUT (opcional) ·1 x Conector TPM (opcional)
- Page 17 Capitolo 1 Caratteristiche principali Specifiche- -Italiano ·Formato micro ATX: 244 mm x 208 mm Dimensioni · Socket AM2 per processori AMD AthlonTM 64 X2, AthlonTM X2, AthlonTM 64 e SempronTM · Socket AM2+ per processor AMD PhenomTM · Supporto tecnologia HyperTransportTM ·Northbridge: AMD 690V Chipset ·Southbridge: AMD SB600...
- Page 18 Capitolo 1 Caratteristiche principali Connettori I/O ·2 x Collettori USB 2.0 (supportano 4 porte USB 2.0) interni ·4 x Connettori SATA ·1 x Connettore Floppy ·1 x Connettore IDE ·1 x Collettore intrusione telaio (INTR) ·1 x Collettore CD_IN ·1 x Collettore S/PDIF_OUT (optional) ·1 x CollettoreTPM (optional) ·1 x Collettore TV_OUT ·1 x Collettore porta COM2 (optional)
-
Page 19: Технические Характеристики
Глава 1 Основные характеристики Технические характеристики- -Русский Размер ·Форм-фактор микро-ATX размером 244 х 208 мм · Гнездо AM2 для процессоров AMD AthlonTM 64 X2, Процессор AthlonTM X2, AthlonTM 64 и Sempron · Гнездо AM2+ для процессор AMD PhenomTM · Поддержка технологии HyperTransport Набор... - Page 20 Глава 1 Основные характеристики ·2 Разъемы USB 2.0 (поддержка 4 портов USB 2.0) Встроенные ·4 Разъемы SATA входы и ·1 Разъем дисковода гибких дисков выходы ·1 Разъем IDE ·1 Разъем датчика открывания корпуса (INTR) ·1 Разъем CD_IN ·1 Разъем S/PDIF_OUT (дополнительный) ·1 Разъем...
-
Page 21: Pci Express X16
اﻟﺨﺼﺎﺋﺺ اﻟﺮﺋﯿﺴﯿﺔ اﻟﻔﺼﻞ اﻟﻤﻮاﺻﻔﺎت ﻟﻌﺮﺑﯿ ﺔ اﻟﺤﺠﻢ ﻣﻢ × ﻣﻢ ﻣﻘﺎس Micro ATX ﺣﺎوﯾﺔ ﻣﻦ ﻧﻮع Ÿ وﺣﺪة اﻟﻤﻌﺎﻟﺠﺔ اﻟﻤﺮﻛﺰﯾﺔ Ÿ AthlonTMX2 و AMD At hlonTM64X2 ﻟﻤﻌﺎﻟﺠﺎت ﻣﻘﺒﺲ AthlonTM 64 and SempronTM و AMD PhenomTM ﻟﻤﻌﺎﻟﺠﺎت AM2 + ﻣﻘﺒﺲ Ÿ HyperTransportTM دﻋﻢ... - Page 22 اﻟﺨﺼﺎﺋﺺ اﻟﺮﺋﯿﺴﯿﺔ اﻟﻔﺼﻞ ﻣﻨﺎﻓﺬ ﺗﻮﺻﯿﻞ اﻟﺪﺧﻞ / اﻟﺨﺮج USB 2.0 ﻣﻨﺎﻓﺬ ﺗﺪﻋﻢ USB 2.0 ﺗﻮﺻﯿﻞ أﻃﺮاف ﻋﺪد Ÿ اﻟﺪاﺧﻠﯿﺔ SATA ﻣﻨﺎﻓﺬ ﺗﻮﺻﯿﻞ ﻋﺪد Ÿ ﻣﻨﻔﺬ ﺗﻮﺻﯿﻞ ﻣﺤﺮك اﻷﻗﺮاص اﻟﻤﺮﻧﺔ ﻋﺪد Ÿ ﻣﻨﻔﺬ ﺗﻮﺻﯿﻞ ﻋﺪد Ÿ (INTR ﻟﻠﮭﯿﻜﻞ Intruder ﻃﺮف ﺗﻮﺻﯿﻞ ﻋﺪد...
-
Page 23: Jumpers
Chapter 1 Main Features Jumpers This section explains how to setup jumpers. You should read the following content carefully prior to modifying any jumper settings. Attention The jumpers on the motherboard, pin 1 can be identified by the bold silkscreen next to it. And in this manual, pin 1 is simply la- beled as “1”. - Page 24 Chapter 1 Main Features Keyboard and Mouse Jumper: KB/MS_PWR This jumper allows you to enable or disable the Key- (Default) board and Mouse wake-up feature. Set the jumper to pins 2-3(+5VSB) to wake up the computer from sleep +5VSB modes when you press a key on the keyboard or click the mouse, and a corresponding setting must be set KB/MSPWR in BIOS as below:...
-
Page 25: Chapter 2 Bios Description
Chapter 2 BIOS Description Chapter This chapter introduces how to change system settings through the BIOS Setup menus. You have to run the Setup Program when the following cases occur: 1. An error message appears on the screen during the system POST process. -
Page 26: Enter Bios Setup
Chapter 2 BIOS Description Enter BIOS Setup The BIOS is the communication bridge between hardware and software. Correctly setting up the BIOS parameters is critical to maintain optimal system performance. Power on the computer, when the following message briefly appears at the bottom of the screen during the POST (Power On Self Test), press <Del>... -
Page 27: Standard Cmos Features
Chapter 2 BIOS Description 6. Power Management Setup Through this menu you can set up all the Power Management events related items. 7. PnP/PCI Configuration The system’s PnP/PCI settings and parameters can be modified by this menu. 8.PC Health Status This menu will display the current status of your PC. - Page 28 Chapter 2 BIOS Description Day—weekday from Sun. to Sat. Month—month from 1 to 12 Date—date from 1 to 31 Year—year, set up by users. Use <ENTER>,<TAB> or <SHIFT+TAB>to select a field.Use <+>or <-> to configure system time and date. 1.3 IDE Configuration You may set configurations for the IDE device that you specify through this item.
-
Page 29: Central Control Unit
This item tells you the maximum speed of the front side bus. 2.5 Current Memory Clock This item shows the current memory clock frequency automatically. 2.6 FOXCONN Feature Press “Enter” to set the characteristic features of FOXCONN. 2.1 Clock Generator Settings Clock Generator Settings Menu 2.1.1 CPU Frequency Multiplier... -
Page 30: Advanced Bios Features
Use this item to enable or disable the spread spectrum functions. NOTE: The Spread Spectrum function can influence the EMI (Electromagnetic Interference)degree. 2.6 FOXCONN Feature FOXCONN Feature Menu 2.6.1 CPU Voltage Control Use this item to adjust the CPU core voltage manually. The voltage range is +25mv~+800mv. -
Page 31: Advanced Chipset Features
Chapter 2 BIOS Description Advanced BIOS Features Menu 3.1 CPU Configuration Press “Enter”, you will see the CPU-related information that the BIOS automati- cally detects. 3.2 Boot Settings Configuration Press “Enter”, you are able to specify the boot device priority sequence from the availabe devices. -
Page 32: Integrated Peripherals
Chapter 2 BIOS Description AMD 690G/690V Configuration This sub-menu allows you to configure the parameters of Internal Grapgics and PCI Express. 4.2 NorthBridge Configuration This sub-menu allows you to set the memory configuration and enable or disable the power down function. 5.Integrated Peripherals Integrated Peripherals Menu 5.1OnChip SATA Channel... -
Page 33: Power Management Setup
Chapter 2 BIOS Description 6.Power Management Setup Power Management Setup Menu 6.1Cool ‘N’ Quiet Enable or disable AMD “Cool ‘N’ Quiet” technology. Cool’N’Quiet is a CPU speed throttling and power saving technology introduced by AMD with their Athlon 64 processor line. It works by reducing the processor’s clock rate and voltage when the computer has low usage. -
Page 34: Pnp/Pci Configuration
Chapter 2 BIOS Description 6.7 RTC Resume This item allows you to resume system by RTC alarm. 7.PnP/PCI Configuration PnP/PCI Configuration Menu 7.1Clear NVRAM This item allows you to clear NVRAM(Non Volatile Random Access Memory) during System boot. 7.2 Plug & Play O/S When set to “NO”,the BIOS will configure all devices in the system.When set to “Yes”... -
Page 35: Pc Health Status
Chapter 2 BIOS Description 7.9 DMA Channel 0/1/3/5/6/7 Use this item to specify DMA Channel for PCI/PnP devices to use. The default value is“Available”. 7.10 Reserved Memory Size This item allows to reserve size of memory block for legacy ISA deices.W e advise to keep the default value unchanged.The default value is “Disabled”. -
Page 36: Load Optimal Defaults
Chapter 2 BIOS Description 9.1 Supervisor/User Password These items show supervisor/user password installed or not. 9.2 BIOS Write Protection Enable this item to protect system BIOS from viruses. 9.3 Change Supervisor Password Press “Enter” to change the supervisor password. The access rights and permissions associated with the Supervisor password are higher than those of a regular User password. - Page 37 Chapter 4 Driver CD Introduction Chapter This chapter will introduce how to use attached software. This chapter provides the following information: FOX ONE FOX LiveUpdate FOX LOGO FOX DMI...
-
Page 38: Chapter 3 Directions For Bundled Software
Chapter 3 Directions for Bundled Software FOX ONE FOX ONE is a powerful utility for easily modifying system settings. It also allows users to monitor various temperature values, voltage values, frequency and fan speed at any time. With FOX ONE, you can modify system performance settings such as bus speed, CPU voltage, fan speed, and other system performance options that are supported by the BIOS and you also can monitor hardware temperature, voltage, frequency and fan speed. - Page 39 CPU’s loading. F.I.S calibration function is optional. Homepage Click this button to visit FOXCONN motherboard website. 2. CPU Page - CPU Control This page is used to select and run the CPU frequency to determine the current performance level of the system.
- Page 40 Chapter 3 Directions for Bundled Software 3. Freq. Page - Frequency Control In this page ,you can set memory and PCI Express frequency manually. Go to Freq. page Close this page Select the option you want to set Adjust manually Reset the changes Apply the changes 4.
-
Page 41: Fox Liveupdate
Chapter 3 Directions for Bundled Software Go to Voltage page Select the option you want to set Adjust manually Reset the changes Apply the changes 6. Fan Page - Fan Control This page allows you to enable Smart Fan function and set fan speed manually. Go to Fan page Enable or disable smart fan function... - Page 42 Chapter 3 Directions for Bundled Software Using FOX LiveUpdate: 1. Local Update “BIOS Info” tells you the system BIOS information; “Backup BIOS” could backup your system BIOS ,please click this button ,then key in a BIOS name and save it ; “Update BIOS” helps to update your system BIOS from local BIOS files ,please follow the wizard to finish the operation.
-
Page 43: Fox Logo
Chapter 3 Directions for Bundled Software Click the “System” button,you can set the backup BIOS location and change different skin of the utility;“Advance”helps you to flash BIOS,Boot Block and clear CMOS ,we recommend that you keep the default setting unchanged to avoid damagement. Set auto search options Click here... -
Page 44: Fox Dmi
Chapter 3 Directions for Bundled Software Main Page Main screen Exit Backup Minimize Change W ebsite About D e l e t e Warning: When you change Logo or delete the current Logo, the system will flash BIOS file automatically.During this time, please DO NOT shut down the application and the system, or the motherboard will be damaged seriously.
