BOSSCOM Powerlink-Switch
(Powerlink Converter / Automatic Source Switching with RCA and 8-pin DIN Inputs, B&O
Example of Use 3
Dolby Surround Setup for LOEWE
Switching (with trigger signal)
Front Speakers
®
e.g. BeoLab 8000
TV with Dolby
Surround
decoder, like
®
LOEWE
®
Individual
®
B&O System e.g.
®
BeoSound 3200
Rear Speakers
®
e.g. BeoLab 3
In the example shown, you can enjoy Dolby Surround Sound for TV and Speaker-4 sound when listening
to the audio system - and all this completely automatically. You do not need to unlock the source on the
B&O system with the B&O remote control - you simply turn on the TV and the B&O
on automatically. The following applies: If both sources are active, INPUT 1 has priority!
®
TV and B&O
Front Speakers
Use two BOSSCOM Powerlink switches and
®
e.g. BeoLab 8000
connect for example your LOEWE
B&O
the two front channels of your TV to the front
speakers, via INPUT 1 of the first BOSSCOM
Powerlink switch and the two rear channels to
the two rear speakers, via the second BOSSCOM
Powerlink switch.
Your stereo source - in this example, a BeoSound
3200
BOSSCOM Powerlink switches. You will need
an additional power Y-cable link.
You can also create a trigger level, by connecting
the adapter cable (included) to each INPUT 1 of
the BOSSCOM Powerlink switch, if the audio
source provides such, like the LOEWE
example shown. The advantage of using the
2 x BOSSCOM
trigger level on INPUT 1 is that is the automatic
PL-Switch
switch to INPUT 2 is no longer initiated after a lag
of about 1 minute without audio signal, but
immediately when the trigger level is no longer
present - this way you don't need to wait, to be
able to listen to the audio source of INPUT 2.
Rear Speakers
®
e.g. BeoLab 3
®
Compatible)
®
Systems with Automatic
® ®
system and your B&O
®
- is connected to INPUT 2 of both
®
®
TV to your
speakers. Connect
®
TV in the
speakers are turned
