- Page 1 MR5mk3, MR6mk3, MR8mk3 Powered Studio Monitors O W N E R ’ S M A N U A L...
-
Page 2: Important Safety Instructions
Loudest parts at a rock concert fonctionnement et l'entretien (service) dans le livret d'instruction accompagnant l'appareil. WARNING — To reduce the risk of fire or electric shock, do not MR5mk3 / MR6mk3 / MR8mk3 expose this apparatus to rain or moisture. -
Page 3: Table Of Contents
Perfectly matched amps and drivers for optimized 6. INPUT LEVEL ..............7 performance 7. CUSTOM-TUNED REAR PORT ...........7 • 50 watts of Class A/B amplification [MR5mk3] FRONT PANEL DESCRIPTION ............7 • 65 watts of Class A/B amplification [MR6mk3] 8. RUNNING MAN LOGO LED ..........7 •... -
Page 4: Introduction
• Video post-production – Edit suites for small productions such as commercials, budget films or multimedia for internet broadcast, etc. • Home theater and other multimedia – Music and movie playback, video game sound system, social function/party system, etc. MR5mk3 / MR6mk3 / MR8mk3... -
Page 5: Quick Start
Quick Start An Extremely Important Note on MRmk3 Bass Response and We realize that you can’t wait to hook up your MRmk3 Your Control Room Studio Monitors and try them out. Nevertheless, please take the time to read this page NOW, and the rest can wait until you’re good and ready. -
Page 6: Rear Panel Description
AC outlet, the Running Man logo on the front of the monitor illuminates to let you know that it’s ready to go. RCA Unbalanced Connectors For more information on these connectors, see MR5mk3 / MR6mk3 / MR8mk3 Appendix B on page 11. -
Page 7: Input Level
The size of the port is carefully response by: designed with respect to the volume of the cabinet ±2 dB at 3 kHz and above [MR5mk3] and the characteristics of the woofer to produce ±2 dB at 3.25 kHz and above [MR6mk3] low-frequency extension. -
Page 8: Protection Circuits
CRT (cathode ray tube). If you have a particularly sensitive computer monitor or TV screen, it may be necessary to move the speakers a few inches away. MR5mk3 / MR6mk3 / MR8mk3... -
Page 9: Appendix A: Service Info
115 VAC: T 1 AL / 250 V • Is there a light dimmer or other triac-based device on 230 VAC: T 500 mAL / 250 V [MR5mk3] the same AC circuit as the monitor? Dimmers cause 115 VAC: T 1.25 AL / 250 V buzzing noises. -
Page 10: Repair
Visit www.720trees.com and click Support to find: FAQs, manuals, and addendums. • Email us at: techmail@loudtechinc.com. • Telephone 1-800-898-3211 to speak with one of our splendid technical support chaps (Monday through Friday, normal business hours, Pacific Time). MR5mk3 / MR6mk3 / MR8mk3... -
Page 11: Appendix B: Connectors
Appendix B: Connectors Balanced XLR Input Connector Unbalanced RCA Input Connector XLR connectors are used to make balanced RCA-type plugs (also known as phono plugs) connections to the MRmk3 studio monitors. They and jacks are often used in home stereo and video are wired as follows, according to standards specified equipment and in many other applications. -
Page 12: Appendix C: Technical Information
Fuse: 115 VAC: T 1 AL / 250 V 105 dB SPL @ 1m [MR6mk3] 230 VAC: T 500 mAL / 250 V [MR5mk3] 107 dB SPL @ 1m [MR8mk3] 115 VAC: T 1.25 AL / 250 V Maximum SPL Per Pair:... -
Page 13: Mrmk3 Dimensions
MR5mk3 Dimensions 7.8" / 197 mm 10.9" / 276 mm WEIGHT 12.1 lb / 5.5 kg 11.3" / 286 mm MR6mk3 Dimensions 8.7" / 222 mm 12" / 305 mm WEIGHT 15.9 lb / 7.2 kg 12.7" / 323 mm MR8mk3 Dimensions 10.9"... -
Page 14: Mrmk3 Block Diagram
The following are trademarks or registered trademarks of LOUD Technologies Inc.: MR Series and the Running Man. This manual also contains names and marks of other companies which belong to those respective companies, and are hereby acknowledged. ©2013 LOUD Technologies Inc. All Rights Reserved. MR5mk3 / MR6mk3 / MR8mk3... -
Page 15: Mrmk3 Limited Warranty
Limited Warranty Please keep your sales receipt in a safe place. This Limited Product Warranty (“Product Warranty”) is provided by LOUD Technologies Inc. (“LOUD”) and is applicable to products purchased in the United States or Canada through a LOUD-authorized reseller or dealer. The Product Warranty will not extend to anyone other than the original purchaser of the product (hereinafter, “Customer,”... - Page 16 16220 Wood-Red Road NE Woodinville, WA 98072 • USA Phone: 425.487.4333 Toll-free: 800.898.3211 Fax: 425.487.4337 www.720trees.com...
