CHAPTER 2 SYSTEM CONFIGURATION

2.1 The System Unit Chassis:

The following information will help you to acquaint yourself with the arrangements of the
Pyramid LCD Monitor.
When you open the box, you will find the items detailed in Figure 2.1 below:
Pyramid 15" LCD Monitor
Accessory Package
AC power Cord
DC 12V Adapter
Customer Display (Optional)
Magnetic Stripe Reader (Optional)
Magnetic Stripe Reader + Smart Card Reader (Optional)
AC Power Cord
DC 12V Adapter
Figure 2.1 shows the full packing box. In the side compartments of each box you will find the
Monitor, AC power cord, DC 12V adapter, accessory package, VFD customer display
(optional) and magnetic stripe reader (optional) or magnetic stripe reader + smart card reader
(optional).
Customer Display
in Accessory BOX
(Optional)
8
1. Magnetic Stripe Reader
2. Magnetic Stripe Reader +
Smart Card Reader
(Optional)
Accessory Package
Figure 2.1
