3.2 Magnetic Strip Reader (MSR)

The Pyramid LCD has also incorporated an ISO track 1/2/3 MSR with a keyboard wedge
interface onto the side of the LCD display.
3.2.1 General Characteristics
Read/Write
Direction
Speed
Lift Cycle
3.2.2 Track Information
Track
Standard
Recording Method
Recording Density
Capacity
3.2.3 Electrical Characteristics
Supply Voltage
Power Consumption (Typ.)
Output Voltage (Typ.)
Output Voltage (Min.)
Output Low Voltage
3.2.4 Physical Characteristics
Weight
Body Material
Cover Weight
Cable Weigh
Cable Length
Decoder Board Weight
3.2.5 Environment
Operating temperature
Storage Temperature
Operating Humidity
Read
Bi-direction
100 – 1000 mm/sec
Approx. 300,000 passes (1,000,000 passes is optional)
1
IATA
F2F (FM)
210 BPI
79 Characters
7 Bits/Characters
DC +5V ±5%
20 mA
+5V
4.5V
0.4V
36g/1.27oz
PC & ABS
18g/0.64oz
Approx. 4 g / 0.14 oz
230 mm (9.05 lnch)
Approx. 11 g / 0.35 oz
°C °C °C
0 to 50 (32 to 122
°C °C °C
-20 to 70 (-4 to 158
20% to 95% (Non-condensing)
2
ABA
F2F (FM)
75 BPI
40 Characters
5 Bits/Characters
°C
)
°C
)
17
3
THRIFT/MINTS
F2F (FM)
210 BPI
107 Characters
5 Bits/Characters
Power ON (Red)
Good Reading (Green)
