GMX 5597/1
On/Off button
Press the ON button to switch on the dishwasher.
The indicator lamp of the last programme selected
lights up; at the end of the cycle a short acoustic
signal sounds.
Programme selection button
Press the button to select a programme.
The corresponding indicator lamp lights up.
Indicators
Add regeneration salt
Only add regeneration salt immediately before
starting a wash programme.
Add rinse aid

Additional options (*)

"Half Load" function
Recommended when the dishwasher is not full to
save water and electricity. When it is selected
(indicator lamp on), only the upper rack or the
lower rack will be washed.
WARNING: This function remains selected until
switched off.
Antibacterial Rinse
(Sani Rinse option)
This function adds an antibacterial rinse at the
end of the wash cycle, thereby further reducing
bacteria levels. The lamp will light up when the
function is activated. If the temperature is not
maintained during the antibacterial cycle (e.g. if
the door is opened or a power failure occurs),
the lamps will start blinking to indicate that the
antibacterial action is not guaranteed.
"Delayed start" and "Water
hardness setting" button
T o set the water hardness level, follow the
instructions in the enclosed handbook. The wash
cycle can be programmed to start after 1-9 hours.
The delayed start can be programmed either before
or after selecting the desired wash programme.
When the door is closed, a pre-wash cycle is run,
after which the delayed start countdown begins.
Programmes
Pre-Rinse
Rapid 30 min
1)
Bio/Eco
AutoSensor 60-70°C
Intensive
(*) Options available with all programmes, except prewash.
(**) When the "AutoSensor" programme is selected, wash
parameters automatically adapt to the level of soiling present.
1) Reference programme for energy label in compliance with
EN 50242 regulations (upper rack in upper position);
2) Refer to "User instructions";
Black process 45.0° 150.0 LPI
Before using the dishwasher, read the user instructions!
Quick Reference Guide

Programme chart

Loading Instructions
cold Crockery to be washed later.
45°C Lightly soiled crockery with no dried-on food.
55°C Normally soiled crockery.
Normally or heavily soiled crockery.
Recommended programme for heavily soiled
70°C
crockery, especially suitable for pans and saucepans.
Fault indicators
Indicators
Water stop device activated
Switch off the dishwasher and contact the After-Sales
Service.
The dishwasher over fills with water
Reset and start the programme again from the beginning.
If the problem persists, contact the After-Sales Service.
The water heating system is not working
Reset and start the programme again from the beginning.
If the problem persists, contact the After-Sales Service.
Water heating anomaly
Reset and start the programme again from the beginning.
If the problem persists, contact the After-Sales Service.
The dishwasher does not fill with water
Check the water supply and filters, and make sure that
there are no kinks in the water inlet hose. Open and
close the door in order to continue.
The dishwasher does not drain
Make sure that the filter unit and drain hose are not
clogged and if necessary clean them.
Flow meter (if provided) anomaly
Reset and start the programme again from the beginning.
If the problem persists, contact the After-Sales Service.
Alternate washing system (if provided)
anomaly
Reset and start the programme again from the beginning.
If the problem persists, contact the After-Sales Service.
Fault in water load system
Switch off the dishwasher and contact the After-Sales
Service.
2)
Detergent
A B
- -
X -
X X
X X
X X
3) Programme data obtained in conformity with European
standard EN 50242. Values may vary in relation to usage, e.g.:
different loads, water temperatures - above or below 15° C -
as well as water hardness and power supply voltage, etc.
5019 496 96032
(We reserve the right to make technical modifications)
GB
Off
Blinking
On
3)
Consumption
Litres kWh Minutes
6.0 0.03 16
13.0 0.80 30
14.0 1.08 180
(**) (**) (**)
20.0 1.60 110
