CARACTERÍSTICAS DE LA PLANCHA KENMORE
ALÁMBRICA / INALÁMBRICA
1
2
Arriba
Abajo
3
1. BOTÓN DEL VAPORIZADOR
Al presionar este botón se
produce una poderosa descarga
de vapor sin goteo de agua.
2. BOTÓN DEL ATOMIZADOR
PARA ROCIAR
Al presionar este botón se
produce un chorro definido de agua
atomizada que humedece
suavemente la tela.
REGULADOR DE VAPOR
3.
Para seleccionar planchado en
seco, deslice la palanca hacia
abajo. Para planchado con vapor,
deslice gradualmente la palanca
hacia arriba a fin de aumentar la
cantidad de vapor.
4. DISCO DE CONTROL DE
TEMPERATURA
Gire el disco para seleccionar la
temperatura. Los niveles
principales de temperatura se
indican por medio de los puntos
1, 2 y 3. (Vea el "Diagrama de
Planchado".)
5
6
5. BOQUILLA DE LLENADO
La tapa impide la entrada de
polvo y materia extraña al
depósito de agua. También evita
el derrame de agua al planchar.
6. CORDÓN DE PIVOTE
Permite que la plancha se use
con la mano derecha o la
izquierda. Gira hacia arriba y
hacia abajo e impide que la tela
se enrede con el cordón. El
protector flexible evita que el
cordón se desgaste.
21
OPERATING INSTRUCTIONS (CONT.)
CORDED IRONING
Place iron on stand.
Set the 3-position switch to "Cord"
position.
The power unit is now attached to the
iron.
CORDLESS IRONING
Place iron on stand.
Set the 3-position switch to "Cordless"
position.
Always place iron on stand when not in
use.
USER MAINTENANCE INSTRUCTIONS
EMPTYING THE IRON
1. Always empty iron after each use.
2. When finished using the iron, turn
the variable steam control to "0" and
the temperature control dial to "MIN".
3. Unplug the iron from the electrical
outlet.
For optimal ironing performance, the
iron should be replaced on the stand for
heating up to the set temperature. As
soon as the soleplate has reached the
set temperature, the thermostat light will
go off.
The soleplate will cool down after
cordless ironing for a considerable
amount of time. Use the cord for lengthy
periods of ironing.
ELECTRONIC AUTOMATIC
SHUT-OFF
The Kenmore Cord/Cordless is equipped
with an electronic auto shut-off. The
electronic auto-off switches the iron off if it
has been standing unmoved for
approximately 8 minutes. A red light will
flash when the iron switches itself off. To
switch the iron back on, just shake the
iron side-to-side several times.
4. Set variable steam control to "MAX".
5. Turn the iron upside down over the
sink with the tip pointing downward
and allow the water to flow from the
opening.
6. Set variable steam control to "0".
7. Allow iron to cool on stand before
storing.
WARNING!
Use caution when
emptying the iron. Burns may occur
from touching hot metal surfaces,
hot water or steam.
10
