Entelli-Switch 250 User Setup - System Info
18
ZBTS / ZBTSD Operation and Maintenance Manual (71R-4000A)
View System Data
Enter six digit access code
(The factory assigned six-digit access code
is located on the back of the controller)
1
4
2
5
3
6
Engine Start Relay (De-Energized)
Network Communications
(Option)
J2
*
1
PROG 1
2
PROG 2
3
GRD (Input Sink)
4
LS OUT
5
NIA OUT
6
ELEV. PRE. OUT
7
ALARM OUT
8
STE OUT
9
10
MOTOR DISC. OUT
11
12
TMS IN
13
INHIB.>S1
14
INHIB.>S2
15
LS IN
16
*
Input and output availability
J4
subject to factory configuration.
*
1
2
3
+12v (Output Source)
4
LN OUT
5
L4 OUT
6
Lithium Battery
L3 OUT
7
L2 OUT
8
L1 OUT
9
YN IN
10
User Access Code
YE IN
11
TSNL IN
PRODUCT INFORMATION
12
Q2/TSL IN
13
S12 IN
24-Hour Service
14
S5 IN
Figure 11
WARNING
1
Controller Inputs must be relay Isolated.
A2
A1
14
11
12
RELAY
(-)
(+)
COM
J2-3
Customer
Input
N.O
N.C
Voltage
To
J2/J4
Inputs
2
Controller Outputs have Limited Source Capacity.
Use only GE Zenith-specified Output Modules.
A1
11
14
12
(+)
R1
A2
21
24
22
(-)
Output
Contacts
11
14
12
21
24
22
R1 Output
R1 Output
Contact Rating: 10A @ 250 VAC or 30 VDC
Exerciser Battery
Replacement-K-4100 (BR2032)
Service Life-10 Years
† During normal operation
Default-121212
www.geindustrial.com
(773)299-6600
TM
Entelli-Switch MX250
