RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
INSTALLATION
INSTRUCTIONS
43" Wood Burning Fireplaces
P/N 850,027M REV. A 05/2005
MODELS
ME43
This installation manual will enable you to obtain a safe, efficient and
dependable installation of your fireplace system. Please read and under-
stand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any
circumstances. Any modification or alteration of the fireplace system,
including but not limited to the fireplace, chimney components and
accessories, may void the warranty, listings and approvals of this system
and could result in an unsafe and potentially dangerous installation.
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS DOORS:
INSTALL THIS FIREPLACE IN A SQUARE AND PLUMB CONDITION,
USING SHIMS AS NECESSARY AT SIDES AND/OR BOTTOM.
A French manual is available upon request. Order Form Number
850,027CF.
Ce manuel d'installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 850,027CF.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
ELITE SERIES
Listed to standard: ULC-S610
UL-127
PIME43
1
