USER MANU AL GUIDE
GUIDE D'UTILISATION
MODO DE EMPLEO
PORTABLE AIR CONDITIONER
CLIMATISEUR MOBILE
AIRE ACONDICIONADO PORTATIL
Model #KY-25/Y:
9000 BTU PORTABLE
DIGITAL AIR CONDITIONER
WHITE METAL
METAL BLANC
METAL BLANCO
9,000BTU
9,000BTU
Model #KY-25/Y:
9000 BTU PORTABLE
DIGITAL AIR CONDITIONER
STAINLESS STEEL
ACIER INOXYDABLE
ACERO INOXIDABLE
Advertisement
Table of Contents
Related Manuals for Sunbeam KY-25
Summary of Contents for Sunbeam KY-25
- Page 1 USER MANU AL GUIDE GUIDE D’UTILISATION MODO DE EMPLEO PORTABLE AIR CONDITIONER 9,000BTU 9,000BTU CLIMATISEUR MOBILE AIRE ACONDICIONADO PORTATIL Model #KY-25/Y: Model #KY-25/Y: 9000 BTU PORTABLE 9000 BTU PORTABLE DIGITAL AIR CONDITIONER DIGITAL AIR CONDITIONER STAINLESS STEEL WHITE METAL ACIER INOXYDABLE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS USE AND CARE GUIDE AND INSTALLATION INSTRUCTIONS ...........1 SECTION 1 IMPORTANT SAFETY INSTRUCTIONS PORTABLE AIR CONDITIONER SAFETY......................2 DANGER AND WARNING...........................2 SAVE INSTRUCTIONS FOR FUTURE REFERENCE....................2-3 SPECIAL RECOMMENDATIONS ........................4 ELECTRICAL REQUIREMENTS ........................4 RECOMMENDED GROUNDING METHOD....................5 LCDI PLUG (US ONLY) ..........................5 UNPACKING YOUR PRODUCT PARTS......................6 TECHNICAL SPECIFICATIONS........................6 SECTION 2... -
Page 3: Important Safety Instructions
SECTION 1 IMPORTANT SAFETY INSTRUCTIONS 1.1 PORTABLE AIR CONDITIONER SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. 1.2 DANGER AND WARNING This is the safety alert symbol. - Page 4 SECTION 1 IMPORTANT SAFETY INSTRUCTIONS This portable air conditioner has been designed to create ideal climate in your room. Use it only for this specific purpose and according to the instructions in this manual. This unit is intended for household consumer use only, and is not for commercial use. Please use the unit in the recommended room size (refer to “Technical Specifications”).
-
Page 5: Special Recommendations
SECTION 1 IMPORTANT SAFETY INSTRUCTIONS 1.4 SPECIAL RECOMMENDATIONS • Place the portable air conditioner in a level spot. Leave at least 20" (50.8 cm) between the unit and the wall. • The plug should always be accessible after the unit is settled. •... -
Page 6: Recommended Grounding Method
SECTION 1 IMPORTANT SAFETY INSTRUCTIONS 1.6 RECOMMENDED GROUNDING METHOD For your personal safety, this portable air conditioner must be grounded. The portable air conditioner is equipped with a power supply cord with a 3-prong grounding plug. To minimize possible electrical shock hazard, the cord must be plugged into a mating 3-prong grounding type outlet, grounded in accordance with all local codes and ordinances. -
Page 7: Unpacking Your Product Parts
Wipe it clean if necessary. g. Then install hot air exhaust duct for condenser side according to the installation instructions. Figure 2 1.9 TECHNICAL SPECIFICATIONS Model # KY-25/Y Color Stainless Steel/White Metal Rate Cooling Capacity 9000 BTU/hr Voltage, Frequency, Phase... -
Page 8: A Note To You
SECTION 2 A NOTE TO YOU Thank you for buying this high quality Sunbeam ® portable air conditioner. To ensure you enjoy years of trouble-free operation, we developed the Use and Care Guide. It contains valuable information about how to operate and maintain your appliance properly and safely. Please read it carefully. -
Page 9: Getting Started
SECTION 3 GETTING STARTED 3.1 TOOLS NEEDED 1. Flat-blade and Phillips screwdrivers 2. Gloves 3. Tape measure 4. Utility knife Figure 4 3.2 ACCESSORIES 1. Indoor terminal end 2. Exhaust duct 3. Window assembly kit 4. Main piece 5. Window kit adapter 6. -
Page 10: Power Supply Cord And Receptacle
SECTION 3 GETTING STARTED 3.3 POWER SUPPLY CORD AND RECEPTACLE • The plug should be well fixed and not damaged. • Do not plug the unit with an adapter. • Be sure the plug is fully inserted into the receptacle. •... -
Page 11: Installation Instructions
SECTION 4 INSTALLATION INSTRUCTIONS 4.1 PORTABLE AIR CONDITIONER INSTALLATION • Find a proper place for the portable air conditioner. Leave at least 20” (50.8cm) space around the unit (Fig. 8). When you use the unit as an air conditioner or a dehumidifier, the hot air must be exhausted out of the room to complete the air exchange of the condenser. -
Page 12: Installing The Ducts In The Wall
SECTION 4 INSTALLATION INSTRUCTIONS 4.3 INSTALLING THE DUCTS IN THE WALL CAUTION MANUFACTURER’S RECOMMENDATION. BEFORE UNDERTAKING ANY INSTALLATION OF DUCTS INTO WALL, WE RECOMMEND THAT YOU CONSULT A KNOWLEDGABLE PROFESSIONAL. A) You do not need to use window kit adapter. Mount one end of the exhaust duct into a hole of 5.6”/14.22cm in diameter in the wall;... -
Page 13: Operating Your Portable Air Conditioner
SECTION 5 OPERATING YOUR PORTABLE AIR CONDITIONER 5.1 CONTROL PANEL AND OPERATING FUNCTIONS Figure 12 WARNING If the unit is turned off during operation please wait at least three minutes before starting it again. On/Off Button: Use to Start or Stop the unit. Operation Mode Selection Button: Use to select the operation mode: Auto Mode, Fan-Only Mode, Soft-Dry Mode, and Cooling Mode. -
Page 14: Lcd Display Panel
SECTION 5 OPERATING YOUR PORTABLE AIR CONDITIONER 5.1 CONTROL PANEL AND OPERATING FUNCTIONS CONT’D HOW TO SET: When the unit is ON, press the Timer button, “ “ will flash in Timer Set Display Window and the Timer Indicator will be on in the control panel. Pressing the “Up”... -
Page 15: Operating Remote Control (Model Ky-25Y Only)
SECTION 5 OPERATING YOUR PORTABLE AIR CONDITIONER 5.3 OPERATING REMOTE CONTROL (MODEL KY-25Y ONLY) The functionality of the six (6) buttons on the Remote Control are identical to the functionality of the buttons on the Control Panel. Icons for certain buttons may differ slightly. -
Page 16: Auto Operation
SECTION 5 OPERATING YOUR PORTABLE AIR CONDITIONER 5.3 OPERATING REMOTE CONTROL (MODEL KY-25Y ONLY) CONT’D... FAN-ONLY OPERATION: 1) Plug the Power Cord into the power outlet. 2) Turn on the unit by pressing the ON/OFF Button on the control panel or the remote control. 3) Press the Mode Button on the remote control or the control panel until the... -
Page 17: Water Full Indication And Draining
SECTION 5 OPERATING YOUR PORTABLE AIR CONDITIONER 5.3 OPERATING REMOTE CONTROL (MODEL KY-25Y ONLY) CONT’D... TIMER-OFF PROGRAM SETTING: How to set: When the unit is on, after being set with the TIMER-OFF, the unit will stop after your set delay time. 1) Press the Timer Button on the control panel or on the remote control . - Page 18 SECTION 5 OPERATING YOUR PORTABLE AIR CONDITIONER 5.4 WATER FULL INDICATION AND DRAINING CONT’D... 1. Pump Drain 2. Drain Hose 3. Water bucket Figure 16 Figure 15 NOTE: The cooling efficiency of your unit will be affected if the Drain Hose or the Garden Hose is always attached to it.
-
Page 19: Caring For Your Portable Air Conditioner
Rinse the filter and dry it thoroughly in a shaded place. C) Place the filter back into the filter compartment after it is thoroughly dried. D) If the filter is torn or unusable, order a new filter by calling the Sunbeam Customer Service department at 1-877-383-6399 (8:30am-5:30pm E.S.T.). -
Page 20: Troubleshooting
SECTION 7 TROUBLESHOOTING You can solve many common portable air conditioner problems easily, saving you the cost of a service call. Try the suggestions below to see if you can solve your problem without outside help. 7.1 PORTABLE AIR CONDITIONER DOES NOT WORK AT ALL Check if... -
Page 21: Noise And Vibration
SECTION 7 TROUBLESHOOTING 7.2 LOW COOLING CONT’D Check if... Then... The outside temperature Do not operate your portable air conditioner in cooling mode when is lower than 64 F (18 the outside temperature is lower than 64 F (18 Windows and doors are Close all doors and windows. -
Page 22: Electrical Diagram
Manufactured in China for Star Elite, a division of the Elite Group, Inc., Quebec, Canada, H3B 3X9. Star Elite © 2006 Sunbeam Products, Inc., exploitée sous la raison sociale Jarden Consumer Solutions. 1175 Place du Frère André Tout droits réservés.
