PLUS Vision U4-SERIES Quick Manual page 2

U4 - SERIES
Specifications U4-232h
Resolution XGA, 1024 x 768 pixels
RGB Signal XGA (true)
SXGA (compressed)
SVGA/VGA (expansion/true)
Brightness 2000 Lumens
Contrast Ratio 2000:1 (Full on/off)
Aspect Ration 4:3, supports 16:9
Projection Lens F=2.6-2.9
f=27.5-33mm
1:1.2 Manual Zoom
Manual Focus
Digital Keystone Correction +17/-22 degrees
Digital Zoom 2x
Light Resource 180-watt lamp, 1,500 hrs.
2,000 hrs. in Eco-mode
Color Palette 16.7 million colors
Projection Positions Front/rear,
Table/ceiling
Projection Distance 3.9-38ft / 1.2-11.6 m
Image Size 26"-300" diagonal
Video Signal NTSC3.58, NTSC4.43, PAL, PAL-M,
PAL-N, PAL60, SECAM,
YCbCr (NTSC, PAL),
YPbPr (480p, 576p, 720p, 1080i)
Audio Mono 0.5 watt
Special Features
Dimensions Excluding Lens and Stand:
Height 2.08 in./53 mm
Width 7.5 in./190 mm
Length 9.5 in./242 mm
Weight 3.3 lb./1.5 kg
Included Accessories:
Wireless remote control
Power cable (6 ft./1.8 m)
Video cable (6.5 ft./2 m)
S-video cable (6.5 ft./2 m)
3.5 mm mini plug audio cable (6.5 ft./2 m)
3.5 mm stereo plug to RCA
DVI to mini D-sub 15 pin (6.5 ft./2 m)
TM
Soft carrying case
User's manual
802.11b Wi-Fi CompactFlash Card (U4-237)
U4-237
XGA, 1024 x 768 pixels
XGA (true)
SXGA (compressed)
SVGA/VGA (expansion/true)
2000 Lumens
2000:1 (Full on/off)
4:3, supports 16:9
F=2.6-2.9
f=27.5-33mm
1:1.2 Manual Zoom
Manual Focus
+17/-22 degrees
2x
180-watt lamp, 1,500 hrs.
2,000 hrs. in Eco-mode
16.7 million colors
Front/rear,
Table/ceiling
3.9-38ft / 1.2-11.6 m
26"-300" diagonal
NTSC3.58, NTSC4.43, PAL, PAL-M,
PAL-N, PAL60, SECAM,
YCbCr (NTSC, PAL),
YPbPr (480p, 576p, 720p, 1080i)
Mono 0.5 watt
Wireless (802.11b), Compact Flash Memory,
Image Viewer
2.08 in./53 mm
7.5 in./190 mm
9.5 in./242 mm
3.3 lb./1.5 kg
Optional Accessories:
Optional cases
Ceiling mount kit
Presentation Screens
Document Cameras
VGA cables - 10, 25, 50, and 100 ft
Zen Remote -- all-in-one with mouse control, laser pointer
KJ-200 Airprojector (U4-232h)
U4-237
Wireless LAN Card
CompactFlash Card
Presentation Screens
Choose from a variety of portable
presentation screens from PLUS. They will
save the day in any presentation
environment.
Replacement Bulbs
PLUS offers a wide array of replacement
bulbs so you can carry a spare anywhere.
Remote Controls
Choose from a variety of wireless
remotes to fit any presentation
environment.
