Myson FLOORTEC Specification

FLOORTEC Underfloor Heating

Manifold Specification

Application

The MYSON FLOORTEC manifold provides water to an
underfloor heating system of up to 12 loops.

Functions

The manifold provides a quick and simple installation. The unit
consists of a stainless steel manifold complete with all of the
fittings. The manifold has been designed to connect directly onto
a MYSON FLOORTEC manifold control centre without the need
for extra brackets or support.

General Information

1 x Manifold
1 x Auto Air Vent
1 x Pressure Gauge
1 x Pr Isolating Valves
Manifold Adaptors
Seals

Technical Data

MYSON FLOORTEC manifolds are available from a 2 port up to
a 12 port.
All dimensions in mm unless otherwise stated.

Manifold Dimensions

Number of Ports 2
Length (mm)
350
3 4 5
380 415 470
Dimensions
6 7 8
525 580 635
MYSON
9 10 11
690 745 800
12
855
